Mesh Deck
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
-MODEL # FTF-456MD
-
02262020
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Field Tuff FTF-456MD
Summary of Contents for Field Tuff FTF-456MD
- Page 1 Mesh Deck OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. -MODEL # FTF-456MD 02262020...
- Page 2 Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: FTF-456MD Purchase Date: _______________ Save the receipt, warranty, and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.
- Page 3 WORK AREA • Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating the mesh deck. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
- Page 4 ASSEMBLY Step 1 Connect mesh section (B) Male to female mesh section (A) with 2 sets of M10x55mm bolts in area (D) and 2 sets of M10x65mm in area (E) (bed cross bar connection). Do Not tighten hardware at this point. Step 2 Repeat same process with remaining sections.
- Page 5 Step 3 Assemble the 2 halves with 8 sets of M10x20mm bolts/nuts in area (F). Do not tighten hardware at this point. Step 4 Attach the 4pcs frame connector parts (C) with 4 sets M8x65mm bolts/nuts to the bed beam (G); then pre-assemble one M8 x 65 (H) bolt/nut to each frame connector for connecting the bed to the cart frame.
- Page 6 Step 5 To connect the assembled mesh deck to your utility cart frame (FTF-2200UW or ATV-2200HSH), attach the 4pcs frame connector parts (C) using the 4 sets of pre-assemble M8 x 65 (H) bolt/nut to the brackets located on the cart frame as shown in below illustration.
- Page 7 PARTS LIST: Part # Description Qty. Male bed Mesh Female Bed Mesh Frame Connector M10 x 55mm bolts/nuts (for bed beam connection) M10 x 65mm bolts/nuts (for bed cross bar connection) M10 x 20mm bolts/nuts (for bed halves connection) M8 x 65mm bolts/nuts (for frame connectors connection) M8 x 65mm bolts/nuts (pre-assembled on frame connectors) For technical questions, please call 1-218-943-6296.
