- Page 1 3pt Fur rower with 2 Shovels OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # FTF-21F3PT 04042022...
- Page 2 Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only.
- Page 3 WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a 3pt furrower with 2 shovels. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
- Page 4 ASSEMBLY 1. Connect Horizontal Bracket (#2) to the Middle Post (#1) with Bolt and Nut (#9), (#10). 2. Attach Linkage Plate (#3) to Horizontal Bracket (#2) with Joint Pin with thread end (#6) and Bolt and Nut (#8). 3. Connect Plough (#4) or Middle Buster Plough (#5) to Middle Post (#1) with Bolt and Nut (#11).
- Page 5 DIAGRAM & PARTS LIST Part# Description Qty. Part# Description Qty. Middle Post Clevis Pin 19 Bolt M12x85 with Horizontal Bracket Bolt M12x75 with Linkage Plate Bolt M12x120 with Plough Middle Buster Bolt M10x90 with Plough Joint Pin with thread end (M22) For replacement parts and technical questions, please call 1-218-943-6296.
