Field Tuff Tuff FTF-063PTSD Owner's Manual

3pt 6" spike drag
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

3PT 6' Spike Drag
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Model # FTF-063PTSD
04272021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tuff FTF-063PTSD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Field Tuff Tuff FTF-063PTSD

Summary of Contents for Field Tuff Tuff FTF-063PTSD

  • Page 1 3PT 6’ Spike Drag OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # FTF-063PTSD 04272021...

  • Page 2: Technical Specifications

    Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only.

  • Page 3: Work Area

    WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a 3PT 6’ Spike Drag. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
  • Page 4 ASSEMBLY 1. Install 29pcs Spikes (#5) on the Pipes (#1#2#3) with Self-locking nuts (#13) as below picture shows. Note: The bottom face of the spikes are all facing back. 2. Insert Lift connecting plate (#6) and Right connecting plate (#7) into the Pipes (#1#2#3) in turns.

  • Page 5: Maintenance

    5. Attach Fixed flat bar (#10) and two Lift connecting plates (#6) and Right connecting plate (#7) with Self-locking nuts (#11) and Bolt (#12). 6. Attached Long chain (#17) and Short (#18) to Lift connecting plates (#6), Right connecting plate (#7) and 3pt connector (#4) with Self-locking nuts (#11) and Bolt (#12). Insert (#19) into 3pt connector (#4).

  • Page 6: Diagram & Parts List

    DIAGRAM & PARTS LIST Part# Description Qty. Part# Description Qty. Pipe 1&2 Self-locking nuts M10 Pipe 4&5 Bolt M10x25 Pipe 3 Self-locking nuts M12 3pt connector Spring washer 10 Spikes Washer 10 Lift connecting plate Bolt M10 Right connecting plate Long chain Regulating flat bar Short chain...
