- Page 1 3PT Chisel Plow OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # FTF-5SCP3PT 11082023...
-
Page 2: Intended Use
Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only. -
Page 3: Work Area
SAVE THESE INSTRUCTIONS WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a 3PT Chisel Plow. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •... - Page 4 ASSEMBLY 1. Install Shaft with threaded ends I (#9) onto Long Bracket, Bottom Lug shank (#5) with 2pcs Lock Nut (#30) and 2pcs Flat Washer (#31) as Part A, There are 3pcs of Part A. 2. Install Shaft with threaded ends II (#10) onto Shank, Bottom Lug (#6) with 2pcs Lock Nut (#30) and 2pcs Flat Washer (#31) as Part B, There are 3pcs of Part B.
- Page 5 4. Secure 2pcs Spring (#13) onto Part C with 4pcs R-Pin (#25) and 4pcs Washer (#29) as Part D. There are 3pcs Part D. 5. Install U-Shape Stop (#12) onto Part D using each 2pcs of Bolt (#32), Flat Washer (#33) and Lock Nut (#34) as Part E.
- Page 6 7. Secure Shaft with Thread ends II (#10) with Shank, Top Lug (#7) with 2pcs Lock Nut (#30) and 2pcs Flat Washer (#31) as Part G. There are 2pcs of Part G. 8. Secure Shaft with Thread ends I (#9) with Short Bracket, Top Lug Shank (#8) with 2pcs Lock Nut (#30) and 2pcs Flat Washer (#31) as Part H.
- Page 7 10. Install 2pcs Spring (#13) onto Part I with 4pcs R-Pin (#25) and 4pcs Washer (#29) as Past J. There are 2pcs of Part J. 11. Attach U-Shape Stop (#12) onto Part J by using each 2pcs of Bolt (#32), Flat Washer (#33) and Lock Nut (#34) as Part K.
- Page 8 13. Install 3pcs Part F and 2pcs Part L onto Frame I (#1) and Frame II (#2) with each 20pcs of Bolt (#20), Flat Washer (#26) and Lock Nut (#27) as Part M. 14. Attach 2pcs Support Bar (#4) onto Part M with each 2pcs of Bolt (#18), Lock Nut (#23) and Flat Washer (#24).
-
Page 9: Maintenance
MAINTENANCE • Maintain your 3PT Chisel Plow. It is recommended that the general condition of any 3PT Chisel Plow be examined before it is used. Keep your 3PT Chisel Plow in good repair by adopting a program of conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the problem corrected before further use. -
Page 10: Diagram & Parts List
DIAGRAM & PARTS LIST Page of 12... - Page 11 Part# Description Qty. Part# Description Qty. Frame I Bolt M12*35 Frame II Spring Washer 22 A Frame Bar Nut M22 Support Bar Lock Nut M10 Long Bracket,Bottom Lug Flat Washer 10 Shank Shank, Bottom Lug R-Pin 4.5 Shank, Top Lug Flat Washer 12 Short Bracket,Top Lug Lock Nut M12...
-
Page 12: Warranty
WARRANTY One-year limited parts warranty PO BOX 203 Miltona, MN 56354 MADE IN CHINA Page of 12...
