Appendix A – TLV Data Format
Parameter
(Type)
Tones
(Integer)
Options
(Integer)
TransactionType
(Integer)
Amount
(Decimal)
CashBack
(Decimal)
QwickChipMode
(Boolean)
Reserved
(Integer)
CloseDevice
(Boolean)
EndSession
(Boolean)
SDK - MagneFlex Powder, Middleware| PIN PEDs | Programmer's Manual ( MagneFlex Powder V2 API )
Page 72
Tones to use:
0 = No sound
1 = One beep
2 = Two beeps
Transaction options:
0 = Normal
1 = Bypass PIN
2 = Force Online
4 = Acquirer not available
Type of transaction to be used:
0x00 = Purchase
0x01 = Cash Advance
0x02 or 0x09 = Cashback
0x04 = Goods (Purchase)
0x08 = Services (Purchase)
0x12 = Cash Manual
0x20 = Refund (Chip Card Contactless Only)
0x50 = Payment (Chip Card Contact Only)
The amount to be used and authorized in decimal format.
1.01 = 1 dollar and 1 cent
The amount of cashback to be used and authorized in decimal format.
1.01 = 1 dollar and 1 cent
Start the transaction in Qwick Chip mode. In Qwick Chip mode, the
devices does not prompt for an amount approval and needs no Acquirer
Response (RequestSendAcquirerResponse).
false = Do not do quick chip mode.
true = Quick chip mode.
Reserved for future use. These are the reserved bytes beginning at index
20 of the 0xA2 command. Reference device manual D99875585 for more
details.
Example:
0000000000000000000000000840000100 – Quick Chip Mode
0000000000000000000000000840000003 – PIN Verify
0000000000000000000000000840000004 – PIN Set
Close the connection to the device after the request is processed.
false = Do not close the device. (default)
true = Close the device.
Sends an EndSession command after the request is processed.
false = Do not end the session. (default)
true = End the session.
