CWO-6210 ROTATION CONTROL / WIRING DIAGRAM / ELECTRICAL
COMPONENT CHART
5
= INDICATES ITEMS THAT ARE SUPPLIED TOGETHER.
ELECTRICAL COMPONENT CHART
ITEM DESCRIPTION
1
Toggle Switch
2
Red Neon Lamp
3
Speed Control Board w/Resistor
4
Fuse 2 amp
5
Fuse 3 amp
6
Rotary Switch
3
4
PART NO.
ARM-2279
CWO-6206
CWO-6529
MPD-1026
FUS-0257
MUG-1258-1
6
2
1
27
