CWO-3027 METER KIT ASSEMBLY / EXPLODED VIEW / PARTS LIST

10
1
7
6

CWO-3027 METER KIT ASSEMBLY / WIRING DIAGRAM

11
12
18
ITEM
2
13
8
5
QTY PART NO.
1 48" 900-4-001
2 1 CSR WTE 0187
3 1 CWO-4396
4 1 CWO-4397
5 1 CWO-4399
6 1 CWO-6374
7 1 FAS-0145
8 1 FAS-1340
9 4 FAS-2935
10 5 TERM WTE 0294
11 3 TERM-0024
12 1 TERM-4162
13 1 WAS-0231
9
3
4
3
11
4
11
DESCRIPTION
2 Cond. 18 AWG. SJO Cord
Wire Strain Relief
DC Volt Meter, 0-50 VDC
DC AMP Meter, 0-500 ADC
5" x 7" Front Meter Plate
Alum. Box, Powder Coated
Pan Hd Scr #10-32 x 1/2"
Hex Nut #10-32
Sheet Metal Scr #6 x 3/8"
#10 Ring, Red
1/4" Red Ring
1/4" Blue Ring
#10 Internal Star Washer
10
10
10
