INSTRUCTIONS PARTS MANUAL UNI-BUG II THE UNIVERSAL BUG-O Please record your equipment identification information below for future reference. This information can be found on your machine nameplate. Model Number: Serial Number: Date of Purchase: Whenever you request replacement parts or information on this equipment, always supply the information you have recorded above.
Page 2
SAFETY PROTECT YOURSELF AND OTHERS FROM SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS. EQUIPMENT DAMAGE POSSIBLE. ELECTRIC SHOCK can kill. 1.The equipment is not waterproof. Using the unit in a wet environment 1.
12 ..WIRING DIAGRAM / ELECTRICAL COMPONENT CHART 13 ..EXPLODED VIEW / PARTS LIST BUG-1795 COMPACT CORNER FOLLOWER 14 ..UNI-BUG II FOR DUAL WELDING / RACKMOUNTING / UNI-1019 STEEL DRIVE ROLL 15 ..EXPLODED VIEW / PARTS LIST UNI-1350 UNI-BUG DUAL WELDING GROUP 16 ..
Page 4
4-75 ipm (102-1905 mm/min) with a 50 lb. (22.7 kg) horizontal pulling capacity. The UNI-BUG II is designed to run on the edge of a bar or stiffener up to 2" (50.8 mm) thick as shown below. Front and rear rollers support the machine and tilt it forward for better control and traction.
Page 5
INTRODUCTION (CONT’D.) The UNI-BUG II can operate without a track as shown below. A gear motor turns two drive wheels on one side of the workpiece. On the other side of the workpiece is a bracket which has four idler wheels mounted on it. An idler screw knob is used to move the idler wheel bracket into the workpiece and clamp it between the four idler wheels and the two drive wheels.
TECHNICAL DATA Power Requirement: UNI-1000 120 VAC/50-60/1 UNI-1002 240 VAC/50-60/1 UNI-1004 42 VAC/50-60/1 Dimensions: 8.00" L x 7.62" W x 10. 50" H (203 x 194 x 267 mm) Speed Range: 4 ipm to 75 ipm (102 to 1905 mm/min) Maximum Stiffener Size: 2"...
PARTS LIST / UNI-1000 UNI-BUG II ITEM QTY PART NO. DESCRIPTION BUG-1393 Volt Trap 120 VAC BUG-1415 Pilot Light 120 VAC BUG-1550 Gear Motor (15O: 1) BUG-1725 Precision Speed Control BUG-1785 Handle BUG-1854 Screw Block with Insert BUG-1858 Soc Hd Shr Scr 5/16 x 1 1/4 x 1/4-20...
BUG-1795 COMPACT CORNER FOLLOWER The UNI-BUG II can be used for making fillet welds with the addition of a BUG-1795 Compact Corner Follower, shown at right. EXPLODED VIEW / PARTS LIST / BUG-1795 COMPACT CORNER FOLLOWER ITEM QTY PART NO.
7-1/2" rack to be mounted vertically. At the end of each vertical rack, a swivel clamp assembly and torch clamp are added. A cable anchor with swivel clamp is mounted to the front right side of the UNI-BUG II to complete the set up.
EXPLODED VIEW / PARTS LIST / UNI-1350 UNI-BUG DUAL WELDING GROUP Converts a standard UNI-1000 into a dual welder. ITEM QTY PART NO. DESCRIPTION BUG-1853 Machined Rack 7-1/2" BUG-1881 Cable Anchor w/Swivel Clamp BUG-1891 Double Racker Mounting Angle (includes 2 of item # 4) FAS-0557 Soc Hd Cap Scr 1/4-20 x 3/4 BUG-2708...
UNI-BUG BULB FLAT WELDER UNI-BUG Bulb Flat Welder will weld large bulb angles from 140-430 mm *Spacer Block For 280 to 430 mm Dimensions of machine without torch mounts. 7.62 (194 mm) 6.25 (159 mm) (Torch mounts shown on earlier pages). 5.75 (146 mm) The UNI-1305, Bulb...
UNI-BUG II WITH STITCH MODULE The UNI-1550 is a modification of the UNI-BUG II, that has been adapted to connect to a Stitch Module on a remote pendant. A rotary selector switch enables the Stitch Module, and transfers control of the speed, travel times and weld contactor to the pendant. For safety reasons, the Weld Contact Toggle Switch on the UNI-BUG must be set in the “0”...
TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Does not run. Indicator No input power. - Turn on the circuit breaker. light off. - Plug in the line cord. - Insure there is power at the outlet. Broken Wire. - Unplug the machine from power. - Examine internally and rewire at fault.
Page 19
TROUBLESHOOTING GUIDE (CONT’D.) PROBLEM CAUSE REMEDY Unit runs, but no Faulty control - Unplug the machine from power. speed control. card. Verify there are no bad connections to the control card or on the board. Replace the card. Failed speed - Replace if visually appears damaged.
LIMITED WARRANTY SERIAL NO. __________________ DATE PURCHASED: ___________ FOR A PERIOD OF TWELVE (12) MONTHS FROM DELIVERY, BUG-O SYSTEMS WARRANTS TO THE ORIGINAL PURCHASER (DOES NOT INCLUDE AUTHORIZED DISTRIBUTORS), THAT A NEW MACHINE IS FREE FROM DEFECTS IN MATERIAL AND WORKMANSHIP AND AGREES TO REPAIR OR REPLACE, AT ITS OPTION, ANY DEFECTIVE PARTS OR MACHINE.
