CW-7 CIRCLE WELDER / WIRING DIAGRAM / ELECTRICAL COMPONENT CHART

ITEM DESCRIPTION
*CWO-3139 For Universal Welders
ELECTRICAL COMPONENT CHART
1 Meter Kit Assembly
2 Brush Holder & Support Assembly
3 Power Cable
4 GMA Pigtail
5 GMA Wire Feed Control
6 P.M. Motor Assembly
7 Small Brush Retainer Assembly
8 LN-7 Wire Feeder Assembly
9 Weld Cable 3/0
10 CW-7 Collector
11 Weld Cable Inlet 3/0
12 CW-5 Terminal Block
13 Shunt Bar 500-50
14 Rotation Control Box
15 Solenoid Adaptor Kit
PART NO.
CWO-3027
CWO-3063-2
CWO-3139*
CWO-3331
CWO-3332
CWO-3361
CWE-1530
CWO-3468
CWO-3478
CWO-3495
CWE-1050-3/0
CWO-3955
CWO-6008
CWO-6210
CWO-8057
CWO-3139-M For Miller Welders.
