Motionics BlueTak User Manual

Important Notes
!
Do NOT look into the laser beam.
Do NOT point the laser beam at people.
Do NOT allow children to use the device.
Do NOT allow the laser irradiation port to come in contact with a rotating body.
Do NOT measure using wet or oily hands, or while wearing loosely tting
clothing.
Description
Laser Irradiation Port – source from which the laser is projected
1
Display Screen – displays the measurement value
2
Operation Key 1 – select item
3
Operation Key 2 – con gure settings, select item
4
Operation Key 3 – switch measurement display, enter key
5
Operation Key 4 – return measurement display to normal, cancel key
6
Power/Measurement Key – turn power on (will turn o automatically)
7
Mounting Adapter – allows unit to be mounted on tripod (thread size 1/4-20)
8
Battery Compartment – insert AA batteries
9
6
3
7
Bluetooth Tachometer
BlueTak - User Guide
2 1
4
5
8
9
