Important Notes
!
Turn o the device after use. It will NOT turn o automatically.
Do NOT open the device. Opening causes permanent damage and voids
the warranty.
Description
Sensor Connector – connect to Mitutoyo linear gage with RM12BPE-6PH
1
connector
Tri-Color LED
2
– Device is on
– Device is in charge
– Device is fully charged
Charge Port – connect to cable to charge WiMER3
3
4
1
Wireless Measurement Read
WiMER3 - User Guide
2
4
Product Page
3
Advertisement
Related Manuals for Motionics WiMER3
Summary of Contents for Motionics WiMER3
- Page 1 Description Sensor Connector – connect to Mitutoyo linear gage with RM12BPE-6PH connector Tri-Color LED – Device is on – Device is in charge – Device is fully charged Charge Port – connect to cable to charge WiMER3 Product Page...
- Page 2 Android Quick Start Turn on your WiMER3 and connect it to a Mitutoyo linear gage. Plug in USB Bluetooth dongle if using Windows PC. Run the software, tap Scan/+ button to enter pairing page. Wait for the software to nish scanning nearby devices, select WiMERXXXX to connect.
