Important Notes
!
Do NOT open the device. Opening causes permanent damage and voids
the warranty.
Description
10-Pin Connector – connects to Mitutoyo Digimatic data cable
1
Tri-Color LED
2
– Device is on
– Device is in charge
– Device is fully charged
USB Port – connects to USB cable to charge
3
4
Trigger Connector – 2.5 mm audio port, connects to trigger switch
5
1
Wireless Measurement Read
WiMER1 - User Guide
NOT
2
4
5
3
