Important Notes
!
Do NOT open the device. Opening causes permanent damage and voids
the warranty.
Description
10-Pin Connector – connects to data cable
1
Tri-Color LED
2
– Device is on
– Device is in charge
– Device is fully charged
USB Port – connects to USB cable to charge
3
4
Trigger Connector – 2.5 mm audio port, connects to trigger switch
5
1
Wireless Measurement Read
WiMER2 - User Guide
NOT
5
2
3
4
Product Page
Advertisement
Related Manuals for Motionics WiMER2
Summary of Contents for Motionics WiMER2
- Page 1 Wireless Measurement Read WiMER2 - User Guide Important Notes Do NOT open the device. Opening causes permanent damage and voids the warranty. Description 10-Pin Connector – connects to data cable Tri-Color LED – Device is on – Device is in charge –...
- Page 2 Android Quick Start Turn on WiMER2 and connect to Fowler Test Indicator. Plug in USB Bluetooth dongle if using Windows PC. Run one of the aforementioned Apps/software. In the main page, tap Pair button to bring up a new pairing page.
