Motionics BlueDial User Manual

Important Notes

!
Do NOT open the device. Opening causes permanent damage and voids the
warranty.
BlueDial transmitter & digital indicator should be both on before pairing.
BlueDial operates on two separate batteries:
1) Rechargeable built-in Li-Po battery for the Bluetooth transmitter
2) Coin SR44 or LR44 battery for the digital dial

Description

1
Origin Button – press to zero dial reading; this can also be done in the App
2
Unit Button – select reading in inch/mm
3
SPC Output – SPC data output port
4
Dial Battery – insert coin battery SR44 or LR44 for digital dial
5
6
Status LED
7
– Bluetooth transmitter is on
– BlueDial is in charge
– BlueDial is fully charged
Micro USB Port – connect to USB cable to charge BlueDial
8
4
3
Bluetooth Digital Indicator
1 6
5
7
1
2
BlueDial - User Guide
NOT
6
8
