Default Jumper Settings

Table 2-5. SAM9X60-Curiosity Jumper Settings
Jumper
J4
J14
J15
2.6

Kit Content

The SAM9X60-Curiosity kit includes the following:
• The SAM9X60-Curiosity board inside an ESD bag
• One USB-A to USB Micro-B cable
©
2022 Microchip Technology Inc.
and its subsidiaries
Default Setting
Closed
1-2
1-2
Function
NAND BOOT:
• Opened: Disable BOOT
• Closed: Enable BOOT
RX Selection:
• 1-2: DEBUG RX
• 2-3: CAN0 RX
TX Selection:
• 1-2: DEBUG TX
• 2-3: CAN0 TX
