Smeg PVA96-3 Instructions For Use Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.
INSTRUCTIONS FOR USE .................................................................... 4
2.
3.
SAFETY INSTRUCTIONS ...................................................................... 6
4.
KNOW YOUR APPLIANCE .................................................................... 7
5.
USING THE HOB.................................................................................... 8
6.
CLEANING AND MAINTENANCE ........................................................ 10
7.
INSTALLING THE APPLIANCE............................................................ 11
8.
GAS CONNECTION ............................................................................. 19
9.
ADAPTATION TO DIFFERENT TYPES OF GAS................................. 21
10. FINAL OPERATIONS FOR GAS APPLIANCES................................... 23
Thank you for choosing our product.
We advise you to read this manual carefully. It contains all necessary
instructions for maintaining unaltered the appearance and functional
qualities of the cooking hob.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the autho-
rized person who is to check the gas supply system and install, commis-
sion and test the appliance.
INSTRUCTIONS FOR THE USER: these provide recommendations for
use, a description of the controls and the correct procedures for cleaning
and maintaining the appliance.
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg PVA96-3

Summary of Contents for Smeg PVA96-3

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the autho- rized person who is to check the gas supply system and install, commis- sion and test the appliance. INSTRUCTIONS FOR THE USER: these provide recommendations for use, a description of the controls and the correct procedures for cleaning and maintaining the appliance.

  • Page 2: Instructions For Use

    Precautions for use 1. INSTRUCTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE APPLIANCE.

  • Page 3: Instructions For Disposal - Our Environmental Care

    Do not throw the packing or any part of it away. They can constitute a suffocation hazard for children, especially the plastic bags. Your old appliance also needs to be disposed of correctly.

  • Page 4: Safety Instructions

    WHEN YOU FINISH USING THE APPLIANCE. The manufacturer declines all responsibility for damage to persons or things caused by the non-observance of the above prescriptions or deriving from tampering with any part of the appliance or by the use of non-original spares.

  • Page 5: Know Your Appliance

    Instructions for the User 4. KNOW YOUR APPLIANCE Auxiliary Burner (AUX) Semi-rapid Burner (SR) Rapid Burner (R) Ultra-rapid Burner (URP)

  • Page 6: Using The Hob

    If the burners should go out accidentally, after about 20 seconds a safety device will be tripped, cutting off the gas supply, even if the gas tap is open. In this case, turn the knob to the OFF position and wait at least 60 seconds before trying to light the burner again.
  • Page 7 For better burner efficiency and to minimise gas consumption, use pans with a flat, smooth base and a lid that have a suitable size for the burner, thus avoiding that the flames reach the sides of the pan (see point "5.3 Pan diameters").

  • Page 8: Cleaning And Maintenance

    To clean and preserve the stainless steel surfaces, use only specific products that do not contain abrasives or chlorine-based acids. How to use: pour the product onto a damp cloth and wipe the surface, rinse thoroughly and dry with a soft cloth or deerskin.

  • Page 9: Installing The Appliance

    866 mm 630 mm 50 mm 904 mm 750 mm MAXIMUM 866 mm 650 mm The supporting strips must be of the appropriate size and secured to the base in order to support the weight of the product and its use.
  • Page 10 Instructions for the installer Heights for type B installation (full base) DISTANCES MINIMUM 630 mm 50 mm 904 mm 750 mm MAXIMUM 650 mm...
  • Page 11 Instructions for the installer 7.3.1 Supporting base Make two openings in the rear part of the base as described in the figure below. The left opening must be used for gas connections, and the right one for electrical connections. Before securing the hob to the supporting...
  • Page 12 (C). These operations will guarantee that the entire product is mounted in a stable way. Important: for fixing the product, use the supplied brackets in all the fixing points.
  • Page 13 Important: for fixing this product to the support structure, you are advised not to use mechanical or electrical screwdrivers and to exert moderate pressure by hand on the mounting parts. If this product is installed over an oven, the oven must have a cooling fan.
  • Page 14 If a plug and socket connection is being used make sure that the plug and socket are compatible. Avoid use of adapters and shunts as these could cause overheating and burns.
  • Page 15 However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm. Any other downward facing combustible surface less than 600 mm...
  • Page 16 200 mm, the surface shall be protected in accordance with Clause 5.12.1.2 to a height C of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area. Where the cooking appliance is fitted with a ‘splashback’, protection of the rear wall is not required.

  • Page 17: Gas Connection

    Ensure appliance is secured to wall when installation is completed. N.G. The regulator supplied must be fitted to the ½ BSP thread at the rear of the appliance. An approved manual shut-off valve must be installed. The N.G.
  • Page 18 Air must flow directly into the room through openings in its outside walls. This (these) opening (s) must have a free passage cross-section of at least 100 cm2, or 200 cm2 for appliances not equipped with gas safety device.

  • Page 19: Adaptation To Different Types Of Gas

    Before carrying out the following operations, disconnect the appliance from the electricity supply. The appliance is preset for natural gas NG (2H) at a pressure of 1 kPa. In the case of operation with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.
  • Page 20 NG - 1.0 kPa Nominal gas Injector consumption (mm) (MJ/h) Auxiliary (1) 0.90 Semi rapid (2) 1.20 Rapid (3) 12.0 1.55 Ultra-rapid (4) 15.0 1.75 Arrangement of burners on cooking hob BURNERS 1 Auxiliary 2 Semi rapid 3 Rapid 4 Ultra-rapid...

  • Page 21: Final Operations For Gas Appliances

    "9.1 Replacement of nozzles on the hob" in reverse order. After adjustment with a gas other than the preset one, replace the label on the casing of the appliance with the label corresponding to the new gas.
  • Page 24 914773280/ A...
