Instructions
Matrix 14
Bar Kit
Part No.: 255370 - for One Matrix 14 Meter
Includes Part No.: 121082 - bar plate for installing up to 3 configured Matrix 14 meters
Important Safety Instructions
Read all warnings and instructions in this manual
and the Matrix 14 instruction manual 313046.
Save these instructions.
™
Meter Oil
313013A
ti12303a
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graco Matrix 14
Summary of Contents for Graco Matrix 14
- Page 1 Bar Kit 313013A Part No.: 255370 - for One Matrix 14 Meter Includes Part No.: 121082 - bar plate for installing up to 3 configured Matrix 14 meters Important Safety Instructions Read all warnings and instructions in this manual and the Matrix 14 instruction manual 313046.
-
Page 2: Installation Instructions
(B) (F . 1). ti12218a 4. Install bulk head fitting (3) in meter inlet (F . 4). Use wrench to snug fitting. ti12216a 2. Remove swivel (a) and spacer (b) from Matrix 14 meter (F . 2). ti12219a ti12217a 313013A... - Page 3 5. Install fitting (4) in meter outlet (F . 5). Snug fitting correctly oriented for installation in the oil bar as with a wrench. shown in F . 6. c. Install nut (11) (F . 7). Finger tighten. ti12205a ti12221a 6.
- Page 4 Installing Meter in Oil Bar When installing more than one Matrix 14 meter in the Oil Bar, always install meters from left to right. 1. Install adapter fitting (5) in opening (a) of manifold (14). Tighten securely. Refer to F .
- Page 5 4. Install meter in oil bar housing. 6. Attach fluid outlet tube (2) to fitting adapter (5) on manifold (14) and fluid outlet fitting (4) (F . 15). Fin- Bracket (8) should fit between manifold (14) and the ger tighten both fittings until they are securely oil bar panel cover and notch (e) fits over threads on attached.
-
Page 6: Battery Replacement
Battery Replacement 8. Wrap threads of nipple adapter (13) with PTFE PTFE PTFE ) tape. • If you cannot remove the battery cover from the meter following this battery replacement proce- dure, you will have to completely remove the meter from the oil bar to replace the batteries. •... - Page 7 When you need to perform maintenance or repair work (7) (F . 23). on a meter, follow this procedure to disassemble the oil bar. 1. Relieve pressure following the Pressure Relief pro- cedure described in the Matrix 14 meter instruction manual. ti12231a . 23 313013A...
- Page 8 4. Disconnect fluid outlet tube (2) at both meter 5. Unscrew nipple adapter (13), elbow (6) and swivel adapter (4) and manifold fitting (5). Place a rag nozzle (15) assembly and remove assembly from under the tube to catch any drops of oil that may still manifold (14) (F .
- Page 9 9. To protect meter, lay it face down on a padded sur- face while performing any maintenance or service work on the meter or oil bar. 10. Follow Installing Meter in Oil Bar instructions beginning on page 4 for reassembly instructions. 313013A...
- Page 10 All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. This manual contains English. MM 313013 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC.
