Instruction
Glass Bead Dispense Kits
For professional application of traffic marking reflective beads. Not approved for use in
European explosive atmosphere locations.
Models
17B190 Kit: Replaces 12" bead box with 16" bead box
26D112 Kit: Replaces 12" bead box with 18" bead box
IMPORTANT SAFETY INSTRUCTIONS
Read all warnings and instructions in ThermoLazer Operation manual.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Follow these instructions when removing a smaller bead box and installing the larger 16-inch (40cm) or 18-inch
(45cm) bead box on the ThermoLazer 300TC and ProMelt. Refer to the ThermoLazer Repair and Operation manuals
as needed for additional information.
Related Manuals
Manual in
Description
English
3A1319
ThermoLazer Operation
3A1320
ThermoLazer Repair
334145B
EN
ti24093a
Advertisement
Related Manuals for Graco 17B190
Summary of Contents for Graco 17B190
- Page 1 For professional application of traffic marking reflective beads. Not approved for use in European explosive atmosphere locations. Models 17B190 Kit: Replaces 12” bead box with 16” bead box 26D112 Kit: Replaces 12” bead box with 18” bead box IMPORTANT SAFETY INSTRUCTIONS Read all warnings and instructions in ThermoLazer Operation manual.
- Page 2 Removal Removal Remove Gas Line 2. Disconnect gas tube (373) at valve fitting (151). Discard the hose assembly. Close manual gas shut-off valve on propane tank. ti24109a 1. Disconnect gas hose at the tee on the frame above the drive axle. This hose assembly goes to the rear screed burner manifold.
- Page 3 Removal 2. Remove three screws that hold die support rod to 2. Remove torch holder (204), mounting screw (141), die shroud. flatwasher (123), and locknut (97). Save for reuse. ti24165a 3. Remove die support rod. Save for reuse. ti24168a Remove Bead Box Assembly 3.
-
Page 4: Installation
Installation Installation Install Bead Box 3. Install torch holder. 1. Loosen screws and slide bead dispenser onto bead box support tube. Align bead box drive wheel with center of unit wheel. ti24189a 4. Slide hose clamps onto bead hoses. 2. Secure to the support tube using the bolts in the 5. - Page 5 Installation Install Shroud Door 6. Connect bead dispenser link to bead dispenser box by installing clevis cotter hair pin (268) removed earlier. 1. Slide die support rod (34) removed earlier into die shroud. Secure die support rod to die shroud with three new screws (105) provided.
-
Page 6: Checks And Adjustments
Installation Install Screed Burner Gas Line Checks and Adjustments 1. Apply pipe sealant to hose fitting. Check gas lines and fittings for gas leaks. Use soap and water mixture or LP-gas leak detector to detect gas 2. Connect gas hose at the tee on the frame above leaks. - Page 7 17B190 Parts 17B190 Parts Ref. Part Description Qty. Ref. Part Description Qty. 17B263 MANIFOLD, torch, die, rear, 16” 17B254 BOX, bead, 16” (40 cm), complete 18F292 MANIFOLD, torch, di e, rear, 18” 26D108 BOX, bead, 18” (45 cm), complete 555458...
- Page 8 Original instructions. This manual contains English. MM Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2021, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
