Wire Gauge

For up to 30 m (almost 100 ft) of cable run a multicore cable with
16 conductors 0,75 mm cross section (18 AWG) can be used.
2
For longer cable runs the power loss shall be taken into account;
consider to use cables with a large cross section to limit power
loss. For longer runs up 150 m (490 ft) the suggested minimum
gauge is 4 mm (12 AWG) yielding about 3 dB loss.
2
Kayman-KY102-EBS
Updating EBS DSP
The Kommander-KA18 amplifier firmware can be updated to EBS
using the K-Monitor software version 1.4.4 or higher.
A. Connect the computer running the K-Monitor software
to the same network comprising the Kommander-KA18
amplifier.
B. Launch the software and let it discover the amplifier.
C. Click on the amplifier icon in the left sidebar: the main
window will show the amplifier parameters.
D. Click on the "double arrow" icon button to start the
firmware update.
WINDOWS and OSX software
K-Monitor
click to go
USER GUIDE
7
