In order to drive the Kayman-KY102-EBS transducers
independently, every pair of strands shall be connected to a
single Kommander-KA18 amplifier channel.
A 16 wires multicore cable shall be used to connect the Kayman-
KY102-EBS loudspeaker to the Kommander-KA18 amplifier.
At the amplifier end, the strands of the multicore cables shall be
terminated with the PC 4/ 4-ST-7,62 flying connectors provided
with the Kommander-KA18 amplifier.
The wiring schematics shall guarantee the proper loudspeaker
woofer to amplifier channel matching.
Strand
Woofer
Label
W1–
1
W1+
W2–
2
W2+
W3–
3
W3+
W4–
4
W4+
W5–
5
W5+
W6–
6
W6+
W7–
7
W7+
W8–
8
W8-
6
Amplifier Amplifier
Polarity
connector channel
COLD (–) –
HOT (+) +
A
COLD (–) –
HOT (+) +
COLD (–) –
HOT (+) +
B
COLD (–) –
HOT (+) +
COLD (–) –
HOT (+) +
C
COLD (–) –
HOT (+) +
COLD (–) –
HOT (+) +
D
COLD (–) –
HOT (+) +
B
A
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
C
D
2 +
– W
W 2
1 +
– W
W 1
A
4 +
– W
W 4
3 +
– W
W 3
B
6 +
– W
W 6
5 +
– W
W 5
C
8 +
– W
W 8
7 +
– W
W 7
D
Amplifier
cable end
