Alexis
Installation Guide
For Model:
ALS24
E192641
net weight of fan: 17.81 lb (8.08 kg)

Table of Contents:

Wiring. pg. 8
Control. pgs. 9 - 10
Warranty. pg. 13
page 1
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alexis ALS24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftmade Alexis ALS24

Summary of Contents for Craftmade Alexis ALS24

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Alexis Installation Guide For Model: Table of Contents: ALS24 Safety Tips. pg. 3 Unpacking Your Fan. pg. 4 Parts Inventory. pg. 4 Installation Preparation. pg. 5 Hanging Bracket Installation. pg. 5 Fan Assembly.
  • Page 2 Activating Your New Smart Fan; Downloading the Bond Home App • Using your smart device, navigate to the application store (Apple App store or Google Play), download the free Bond Home app and create account. • Ensure the fan and receiver are receiving power from the house supply using the remote control to turn the fan and light ON and OFF.

  • Page 3: Safety Tips

    Light kit is dimmable to 10% with the wall control included. Distributed by: Craftmade, 3901 S. 20 Avenue, DFW Airport, TX, 75261; 1-800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.

  • Page 4: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor assembly and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. Check against parts inventory that all parts have been included.

  • Page 5: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that inches the hanging location allows the blades a clearance (76 cm) 7 feet of 7 feet (2.13m) from the floor and 30in. (76cm) (2.13 m) from any wall or obstruction. This fan is suitable for room sizes up to 100 square 8ft.

  • Page 6: Fan Assembly. Pgs

    5. Fan Assembly. set screw stop pin Remove hanging ball from downrod provided by loosening set screw on hanging ball. Lower hanging ball and remove stop pin and then slide hanging ball hanging ball off of the downrod. [Refer to diagram 1.] Loosen yoke set screws at top of motor assembly.
  • Page 7 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet safety cable loop wood box and able to support the fan, you are now ceiling ready to hang your fan. Grab the fan firmly with joist two hands. Slide downrod through opening in wood screw hanging bracket and let hanging ball rest on and washer...

  • Page 8: Wiring

    6. Wiring. WARNING: Turn off circuit breakers to current ground (green fixture from breaker panel and be sure switch is or bare) white supply wire turned to the OFF position. black supply wire CAUTION: Be sure outlet box is properly grounded ground (green or bare) and that a ground wire (GREEN or Bare) is present.

  • Page 9: Canopy Assembly

    7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and remove screw closest to the open hanging bracket end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in screw canopy over loosened screw in hanging bracket and push up.

  • Page 10: Assembly Of Handheld Remote

    8. Assembly of Handheld Remote Control. (cont.) Attach black faceplate to front of wall control; post post hole press down firmly. [Refer to diagram 3.] hole Align holes in wall control with posts located on inside of TOP part of remote control cover and press together firmly.

  • Page 11: Remote Control Operation

    10. Remote Control Operation. ON/OFF slider switch - turns wall control ON or OFF (switch not functional on handheld remote) HIGH button - turns fan to HIGH speed LIGHT LIGHT LIGHT LIGHT MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed OFF button - turns fan OFF LIGHT button - turns light ON/OFF...

  • Page 12: Testing Your Fan

    11. Smart Ceiling Fan Wi-Fi Control. (cont.) (Optional) Without Wi-Fi activation, you will not enjoy the expanded features and functionality of your ceiling fan: Breeze speed setting, Creating Schedules and Voice Activation. 11. Select “Continue”. 12. Select the Wi-Fi network you would like to connect the SBB to. 13.

  • Page 13: Troubleshooting

    WARNING: Failure to disconnect power supply prior to CRAFTMADE LIMITED LIFETIME WARRANTY: troubleshooting any wiring issues may result in serious CRAFTMADE warrants this fan for use as intended injury. under the following provision: CRAFTMADE will replace any fan which has faulty performance due to a Problem: Fan fails to operate.
