Wiring Specifications

Refer to the following steps for details on power and accessory wiring
for the operator.
WARNING
ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND
THE OPERATOR MUST BE MADE BY A LICENSED ELECTRICIAN
AND MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL
CODES.
USE COPPER WIRE ONLY!
AC Power Wiring
1. Find the listing on this page corresponding to the model, voltage
and horsepower rating of your operator.
2. The distance shown in the table is measured in feet from the
operator to the power source. DO NOT EXCEED THE MAXIMUM
DISTANCE. These calculations have been based on standard 115 V
and 230 V supplies with a 10% drop allowable. If your supply is
under the standard rating, the runs listed may be longer than what
your application will handle, and you should not run wire too near
the maximum distance for the gauge of wire you are using.
3. When large-gauge wire is used, a separate junction box (not
supplied) may be needed for the operator power connection.
4. Wire length calculations are based on the National Electrical Code,
Article 430 and have been carefully determined based on motor
inrush, brake solenoids, and operator requirements.
5. Connect power in accordance with local codes. The green ground
wire must be properly connected.
6. Wire insulation must be suitable to the application.
7. Electrical outlets are supplied in all 115 VAC models for convenience
with occasional use or low power consumption devices only. If you
choose to run dedicated equipment from these devices, it will
decrease the distance for maximum length and the charts will no
longer be accurate.
DC Control and Accessory Wiring
1. All control devices are now 24 VDC, which can be run up to
2000 feet with 14 AWG wire.
2. Control wiring must be run in a separate conduit from power wiring.
Running them together may cause interference and faulty signals
in some accessories.
3. A three-wire shielded conductor cable is required to connect two
operators together for dual operation. You must use Belden 8760
Twisted Pair Shielded Cable (or equivalent) only – P/N 2500-1982,
per foot). See Page 23 for details of this connection. Note: The
shield wire should be connected in both the operators.
HSLG Slide Gate Operator Installation Guide
MODEL HSLG SINGLE PHASE POWER WIRING
MAXIMUM DISTANCE (FEET)
VOLTS & HP
SINGLE
115 VOLTS
1/2-HP
115 VOLTS
3/4-HP
115 VOLTS
1-HP
208 VOLTS
1/2-HP
208 VOLTS
3/4-HP
208 VOLTS
1-HP
230 VOLTS
1/2-HP
230 VOLTS
3/4-HP
230 VOLTS
1-HP
MODEL HSLG THREE PHASE POWER WIRING
MAXIMUM DISTANCE (FEET)
VOLTS & HP
SINGLE
208 VOLTS
1/2-HP
208 VOLTS
3/4-HP
208 VOLTS
1-HP
230 VOLTS
1/2-HP
230 VOLTS
3/4-HP
230 VOLTS
1-HP
460 VOLTS
1/2-HP
460 VOLTS
3/4-HP
460 VOLTS
1-HP
- 2 -
DUAL
222 111
354 177
566 283
900 450
1430 715
178 89
282 141
450 255
716 358
1140 570
160 80
254 127
406 203
646 323
1026 513
760 380
1200 600
1924 962
3060 1830
4864 2432
604 302
958 478
1526 763
2424 1212
3856 1928
544 272
864 432
1374 686
2184 1092
3476 1738
894 447
1422 711
2264 1132
3600 1800
5724 2862
710 355
1128 564
1796 898
2852 1426
4538 2269
640 320
1016 508
1616 808
2570 1285
4090 2045
DUAL
1142 571
1816 908
2890 1445
920 460
1464 732
2330 1165
714 357
1136 568
1804 902
1344 672
2137 1069
3400 1700
1084 542
1723 862
2741 1371
840 420
1336 668
2124 1062
3841 1921
6106 3053
9712 4856
3279 1640
5212 2606
8291 4146
2689 1345
4274 2437
6798 3399
WIRE GAUGE
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
12
10
8
6
4
WIRE GAUGE
12
10
8
12
10
8
12
10
8
12
10
8
12
10
8
12
10
8
12
10
8
12
10
8
12
10
8
P1220 X14
