Linear HSLG-121 Installation Manual page 33

MODEL HSLG MECHANICAL PARTS LIST
REF. # PART #
Intermediate Shaft Assembly
2110-240
10 2100-765 Pulley Shaft
14 2200-213 Sprocket, 41-B-9, 5/8" bore
9 2200-309 Double Pulley, 7"
11 2200-233 Set Collar Set, 5/8"
92 2200-215 Precision Bearing, 5/8"
72 2200-333 Key, 3/16" x 1-1/2"
71 2100-1750 Key, 3/16" x 1-1/4"
12 2100-547 Brake Disc
Clutch Shaft Assembly
2110-274
30 2100-1008 Clutch Shaft
28 2200-294 Sprocket, 41-A-36, 1" bore
31 2100-669 Clutch Hub (pinned)
78 2100-1007 Clutch Hub (keyed)
79 2100-564 Clutch Facing
32 2200-306 Clutch Spring
33 2400-061 Hex Nut, 5/8"-18
89 2400-062 Jam Nut, 5/8"-18
81 2400-187 Thrust Washer, 1" x 1/8"
2400-088 Roll Pin, 3/16" x 1-3/8"
27 2200-292 Sprocket, 41-B-12, 5/8" bore
2200-215 Precision Bearing, 5/8"
11 2200-233 Set Collar, 5/8"
70 2400-238 Key, 3/16" x 1-1/4"
82 2400-273 Key, 3/16" x 1/4"
2110-236 Output Shaft Assembly
15 2100-917 Output Shaft, 1"
20 2220-022 Sprocket, 41-A-24 with Bearing
93 2200-119 Bearing only for 41-A-24 Sprocket
21 2110-131 Shifter Block with Pins
25 2200-274 Pillow Block Bearing, 1"
97 2100-1737 Pillow Block Retaining Plate
37 2200-014 Set Collar, 1" x 3/8" LTB
26 2200-091 Set Collar, 1" x 5/8" LTB
73 2400-201 Key, 1/4" x 1-1/2"
16 2200-968 Sprocket, 40-B-22, 1" bore
2400-026 Spring Pin, 3/16" x 1" (Predrilled for Pillow Block)
18 2110-700 Idler Assembly
6 620-101029 Rotary Limit Box Assembly
2500-2347 Limit Switch
2100-057 Standard Limit Shaft
2200-030 Limit Nut
2100-261 Detent Plate
2110-162 Limit Box Enclosure with Cover
2300-945 Plastic Limit Box Cover only
2200-029 Flange Bearing, 1/2" ID
2200-193 E-Ring, 1/2"
2400-203 Spring Washer, 1/2"
7 2200-008 Limit Drive Sprocket, 48-B-10, 1/2" bore
For Drives up to 30 feet wide:
2200-008 Limit Box Sprocket, 48-B-10, 1/2" bore
2200-654 #48 Chain, per foot, 27 Links required
For Drives from 31 to 45 feet wide:
2200-041 Limit Box Sprocket, 48-B-15, 1/2" bore
2200-654 #48 Chain, per foot, 29 Links required
For Drives over 45 feet wide:
2200-276 Limit Box Sprocket, 48-B-20, 1/2" bore
2200-654 #48 Chain, per foot, 30 Links required
34 2200-202 #40 Chain, per foot
36 2400-038 U-Bolt, 4-5/8"
REF. # PART #
HSLG Slide Gate Operator Installation Guide
DESCRIPTION
DESCRIPTION
MOTORS
2500-2307
2500-2308
2500-2309
2500-2310
95 2500-2311
2500-2312
2500-2313
2500-2314
2500-2315
2500-2336
2500-2217
2500-1930
2500-1931
2500-2338
2500-1932
MAGNETIC BRAKES (INCLUDES 41, 42, 44, 45 AND 46)
40 2510-398
2510-399
2510-400
41 2200-983
44 2200-939
46 2100-548
45 2100-541
13 2100-2091
1 2120-359-BT
2120-360-BT
2300-716
2110-643
2200-540
53 2110-234
3 2100-573
94 2200-207
29 2400-149
22 2120-132
23 2100-910
24 2200-291
19 2100-657-BT
75 2400-088
87 2100-2007
88 2400-170
84 2100-258
85 2200-306
86 2400-090
2400-045
5 2200-938
2100-553
90 2200-150
76 2200-027
2100-656-BT
2100-059-BT
96 2200-006
8 2200-654
77 2200-010
91 2400-422
100 2510-248
2100-1760
2500-1495
- 31 -
1/2 HP, 115 VAC, 1 Phase
1/2 HP, 208/230 VAC, 1 Phase
3/4 HP, 115 VAC, 1 Phase
3/4 HP, 208/230 VAC, 1 Phase
1 HP, 115 VAC, 1 Phase
1 HP, 208/230 VAC, 1 Phase
1/2 HP, 208/230/460V, 3 Phase
3/4 HP, 208/230/460V, 3 Phase
1 HP, 208/230/460V, 3 Phase
CAPACITORS
Capacitor for 2500-2307 Motor
Capacitor for 2500-2308 Motor
Capacitor #2 for 2500-2309 Motor
Capacitor for 2500-2310 Motor
Capacitor for 2500-2311 Motor
Capacitor for 2500-2312 Motor
115V
230V
460V
Brake and Puck Assembly
Brake Spring (short)
Brake Rod
Brake Plate
Bracket for Brake
Enclosure Assembly Complete with Door
Door Assembly only
Stop/Reset Button Cover
Lock Assembly with Keys
Replacement Key
Rail Assembly
Spacer Plate
Double Pulley, 2"
Chain, #41, 30 Links
Shifter Lever
Locking Disconnect Lever
Disconnect Spring
Rain Cover
Roll Pin
Gate Bracket
U-Bolt, 3"
Chain Tension Bolt, 1/2"
Clutch/Chain Tension Spring
Hex Nut, 1/2"-13 (4)
Flat Washer, 1/2"
V-Belt, 28" Cogged
Bearing Spacer
#41 Chain, per foot (20 links required)
#41 Master Link
Side Plate, 1/2"
Side Plate, 3/16"
#40 Master Link
#48 Chain, per foot (27 links required)
#48 Master Link
5/16-18 U-Nut (4)
Stop/Reset Button and Bracket Assembly
Stop/Reset Button Mounting Bracket
Stop/Reset Button
P1220 X14
