Quick Guide
Cardio P1
Front View
①
②
①
LED
Indicator: DC power connection status
- Blue light: DC power is well connected to the PC
②
Start / Event
Start record, event marker key
- Short Press: Perform as a marker when
abnormalities such as arrhythmias were found
- Long Press (more than 3 sec): Perform as the
AUTO key for saving, transmission and printing
LED
Indicator: Lead status
- Red light: Lead fault
- Blue light: All leads are well connected
Back View
①
①
ID
Label: Part for ID Label
Connection Ports
①
①
ECG Cable Connection Port
: Electrodes for patient
②
DC Power Cable Connection Port
: Cable connected to PC
②
