*25926276_1218*
Drive Technology \ Drive Automation \ System Integration \ Services
Compact Operating Instructions
®
MOVITRAC
LTP-B
Edition 12/2018
25926276/EN

Advertisement

Table of Contents
loading

Related Manuals for SEW-Eurodrive MOVITRAC LTP-B

Summary of Contents for SEW-Eurodrive MOVITRAC LTP-B

  • Page 1 *25926276_1218* Drive Technology \ Drive Automation \ System Integration \ Services Compact Operating Instructions ® MOVITRAC LTP-B Edition 12/2018 25926276/EN...
  • Page 2 SEW-EURODRIVE—Driving the world...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information........................  4 Scope of this documentation................... 4 Structure of the safety notes ................... 4 Safety notes ..........................  6 Preliminary information .................... 6 Duties of the user...................... 6 Target group ........................ 6 Designated use ....................... 7 Functional safety technology .................. 8 Transport......................... 8 Installation/assembly....................... 8 Electrical connection ....................... 9...

  • Page 4: General Information

    MOVITRAC LTP-B documentation. • All technical documentation from SEW‑EURODRIVE is available for download in PDF format from the SEW-EURODRIVE website: www.sew-eurodrive.de. Structure of the safety notes 1.2.1 Meaning of signal words The following table shows the grading and meaning of the signal words for safety notes.
  • Page 5 General information Structure of the safety notes Meaning of the hazard symbols The hazard symbols in the safety notes have the following meaning: Hazard symbol Meaning General hazard Warning of dangerous electrical voltage Warning of hot surfaces Warning of automatic restart 1.2.3 Structure of embedded safety notes Embedded safety notes are directly integrated into the instructions just before the de-...

  • Page 6: Safety Notes

    Safety notes Preliminary information Safety notes Preliminary information The following general safety notes serve the purpose of preventing injury to persons and damage to property. They primarily apply to the use of products described in this documentation. If you use additional components, also observe the relevant warning and safety notes.

  • Page 7: Designated Use

    Safety notes Designated use Specialist for elec- Any electrotechnical work may only be performed by electrically skilled persons with a trotechnical work suitable education. Electrically skilled persons in the context of this documentation are persons familiar with electrical installation, startup, troubleshooting, and maintenance of the product who possess the following qualifications: •...

  • Page 8: Functional Safety Technology

    Safety notes Functional safety technology Functional safety technology The product must not perform any safety functions without a higher-level safety sys- tem, unless explicitly allowed by the documentation. Transport Inspect the shipment for damage as soon as you receive the delivery. Inform the ship- ping company immediately about any damage.

  • Page 9: Electrical Connection

    Safety notes Electrical connection 2.7.1 Restrictions of use The following applications are prohibited unless explicitly permitted: • Use in potentially explosive areas • Use in areas exposed to harmful oils, acids, gases, vapors, dust, and radiation • Operation in applications with impermissibly high mechanical vibration and shock loads in excess of the regulations stipulated in EN 61800-5-1 •...

  • Page 10: Protective Separation

    Safety notes Protective separation Protective separation The product meets all requirements for protective separation of power and electronics connections in accordance with EN  61800-5-1. To ensure protective separation, all connected circuits must also meet the requirements for protective separation. 2.10 Startup/operation Observe the safety notes in the chapters "Startup"...

  • Page 11: Device Structure

    Device structure Nameplate Device structure Nameplate The following figure shows an example of a nameplate. 27021611319513483 Type designation Example: MCLTP-B 0015-2B1-4-00 (60 Hz) ® Product name MCLTP MOVITRAC LTP-B Version Version status of the device series Recommended motor 0015 0015 = 1.5 kW power Connection voltage 2 = 200 – 240 V...
  • Page 12 Device structure Type designation Country-specific design (60 Hz) 60 Hz design ® Compact Operating Instructions – MOVITRAC LTP-B...

  • Page 13: Installation

    Installation Electrical installation Installation Electrical installation WARNING Electric shock due to charged capacitors. Dangerous voltage levels may still be present inside the device and at the terminals up to 10 minutes after disconnection from the power supply. Severe or fatal injuries. •...
  • Page 14 Installation Electrical installation CAUTION Risk of burns. The surfaces of the braking resistors get very hot when the braking resistors are loaded with P Minor injuries. • Choose a suitable installation location. • Do not touch the braking resistors. • Install a suitable touch guard.
  • Page 15 Installation Electrical installation 4.1.2 Motor temperature protection TF, TH, KTY84, PT1000 Motors with internal temperature sensor (TF, TH, KTY84, PT1000 or similar) can be directly connected to the inverter. If the thermal protection is triggered, the inverter displays the error "F-PTC". For motor protection monitoring, the following types can be selected: •...
  • Page 16 Installation Electrical installation 4.1.4 Overview of signal terminals Main terminals NOTICE Applying voltages of more than 30 V to the signal terminals can damage the control- ler. Possible damage to property. • The voltage applied to the signal terminals must not exceed 30 V. IP20, IP55 and IP66 IP66 with switch option 8 9 10 11 12 13...
  • Page 17 Installation Electrical installation Ter- Signal Port Description minal AI 1 / DI 4 Analog input 1 (12 bit) analog: 0 – 10 V, 10 – 0 V, -10 – 10 V, 0 – 20 mA, 4 – 20 mA, 20 – 4 mA Digital input 4 digital: 0/24 V 0 V 0 V: Reference potential AO 1 / DO 1 Analog output 1 (10 bit) analog: 0 – 10 V, 10 – 0 V, 0 – 20 mA, 20 – 0 mA, Digital output 1...
  • Page 18 Installation Electrical installation Relay terminals NOTICE Possible damage to property Do not connect any inductive loads to the relay contact. Ter- Signal Relay function selec- Description minal tion Relay output 1 reference P2-15 Relay contact (AC 250 V / DC 30 V, max.
  • Page 19 Installation Electrical installation 4.1.6 Wiring diagram WARNING Danger of electric shock. Incorrect wiring can lead to dangerously high voltages. Severe or fatal injuries. • Adhere to the following. In the following applications, always cut-off the brake in the AC and DC circuits: •...
  • Page 20 Installation Electrical installation L2/N F11/F12/F13 (AC-3) L1 L2 ND LT.. L1' L2' L3' L1 L2 L3 MOVITRAC LT.. 9007217635508875 Line contactor between grid and inverter. Brake Main switch (only for unit design IP66/NEMA 4x housing with switch (MC LTP- B..-40)) Connection of BW../BW..T braking resistor Bimetallic relay for protection of the braking resistor * Not with 1-phase 230 V ®...
  • Page 21 Installation Electrical installation Brake control V DC (BMV) V AC V AC (BMK) V AC F14/F15 F14/F15 F14/F15 (A C-3) (A C-3) C-3) (A C-3) (AC-3) white white BM K BG E BG E blue BM V white DR/DT/DV: DR/DT/DV: blue Cut-off in the DC Cut-off in the AC circuit...

  • Page 22: Startup

    Startup User interface Startup User interface 5.1.1 Keypads The inverters in IP20 design are equipped with a standard keypad. The inverters in IP55/IP66 design are equipped with a full text display with language switching function. Both keypads allow for operation and setup of the inverter without additional devices. Standard keypad 9007202188405387 [1] 6-digit 7-segment display...
  • Page 23 Startup User interface Operation Both keypads have 5 keys with the following functions: Start [2] • Enable drive • Changing the direction of rotation • Stop drive Stop [3] • Acknowledge error Navigate [4] • Switch menu • Save parameter values •...
  • Page 24 Startup User interface 5.1.2 Resetting parameters to default settings The following preconditions must be satisfied for the parameters to be reset to the fac- tory setting: • The inverter must not be enabled. • The inverter must not be in fire mode/emergency mode. •...
  • Page 25 Startup User interface 5.1.4 Software LT Shell The LT Shell software enables an easy and quick startup of the inverters. It is avail- able for download on the SEW‑EURODRIVE website. After the installation, perform software updates on a regular basis. In combination with the engineering package (cable set C) and the USB11A interface adapter, the inverter can be connected to the software.
  • Page 26 Startup User interface ® Bluetooth LTP-B L1/L L2/N L3 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 9007216440559755 Parameter module ® 5.1.5 MOVITOOLS MotionStudio engineering software The software can be connected to the inverter as follows: •...

  • Page 27: Automatic Measuring Procedure "Auto Tune

    Startup Auto tune USB11A Terminating connector (120 Ω) RJ10 to RJ10 cable Cable splitter Controller LTP-B L1/L L2/N L3 DHP 11B 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 17186293003 Cable USB A-B Terminating connector (120 Ω) USB11A Cable splitter...

  • Page 28: Startup For Motors

    Startup Startup for motors Startup for motors WARNING If parameter P4-02 is set to "1" (auto tune), the motor may start automatically. Severe or fatal injuries. • Make sure that no persons are within the reach of moving parts of the system. 5.3.1 Startup with asynchronous motors with V/f control 1.
  • Page 29 Startup Startup for motors 5.3.2 Startup with asynchronous motors with VFC speed control 1. Connect the motor to the inverter. During the connection, adhere to the nominal motor voltage. 2. Enter the motor data indicated on the motor nameplate: • P1-07 = Nominal voltage of the motor •...
  • Page 30 Startup Startup for motors 5.3.4 Starting with synchronous motors without encoder feedback (PMVC control) The synchronous motors are permanent magnet motors. INFORMATION The operation of synchronous motors without encoder must be checked in a test ap- plication. Stable operation in this operating mode cannot be ensured for all applica- tion cases.
  • Page 31 Startup Startup for motors 5.3.5 Startup with LSPM motors from SEW‑EURODRIVE DR..J type motors are motors with LSPM technology (Line Start Permanent Magnet motors). 1. Connect the motor to the inverter. During the connection, adhere to the nominal motor voltage. 2.
  • Page 32 Startup Startup for motors 5.3.7 Startup with brushless DC motors (BLDC control) 1. Connect the motor to the inverter. Adhere to the nominal motor voltage when con- necting. 2. Enter the motor data indicated on the motor nameplate: • P1-07 = Internal voltage at nominal motor speed •...

  • Page 33: Operation

    Operation Inverter status Operation Inverter status 6.1.1 Static inverter status The following list shows the status messages for a non-enabled inverter. Message Description StoP Power stage of inverter deactivated. This message is displayed when the motor is at an idle state and no error is present.
  • Page 34 Operation Inverter status Message Message Description 7-segment dis- Full text dis- play play Auto-t Auto-tuning An automatic measurement of the motor parameters is being per- formed. This process can take up to 2 minutes..OL (=Over The output current of the inverter exceeds the current value entered in (Flashing dots)

  • Page 35: Error Codes

    Operation Error codes Error codes Code (in- Code Code CANopen Description Measure verter dis- (MotionSt (MotionStudio Emer- play) udio in in P0-13) gency P0-13) Code 4-20 F 0x71 0x1012 Signal loss 4 – • Check whether the input current lies within the range 20 mA defined in P2-30 and P2-33.
  • Page 36 Operation Error codes Code (in- Code Code CANopen Description Measure verter dis- (MotionSt (MotionStudio Emer- play) udio in in P0-13) gency P0-13) Code ® Enc-09 0x0E 0x1026 HIPERFACE type During the use of Smart Servo Package, a wrong motor/in- is not supported. verter combination was used.
  • Page 37 Operation Error codes Code (in- Code Code CANopen Description Measure verter dis- (MotionSt (MotionStudio Emer- play) udio in in P0-13) gency P0-13) Code 0x01 0x2303 Short-term over- Fault during stop procedure: current at the in- Check for premature brake application. verter output.
  • Page 38 Operation Error codes Code (in- Code Code CANopen Description Measure verter dis- (MotionSt (MotionStudio Emer- play) udio in in P0-13) gency P0-13) Code O-Volt 0x07 0x3206 DC link over- The fault occurs if a high flywheel load or overhauling load is voltage connected, and the excess regenerative energy is transferred back to the inverter.
  • Page 39 Operation Error codes Code (in- Code Code CANopen Description Measure verter dis- (MotionSt (MotionStudio Emer- play) udio in in P0-13) gency P0-13) Code SC-F02 0x2F 0x1033 SBus/CANopen Check: communication • The communication connection between inverter and ex- error ternal devices. •...
  • Page 44 SEW-EURODRIVE—Driving the world SEW-EURODRIVE GmbH & Co KG Ernst-Blickle-Str. 42 76646 BRUCHSAL GERMANY Tel. +49 7251 75-0 Fax +49 7251 75-1970 sew@sew-eurodrive.com www.sew-eurodrive.com...
