Evaporation Instruction Sheet
60-5272-001
Ecodyst Hydrogen Rotavap
Benchtop Evaporation System
Installation Guide
keywords: Ecodyst Hydrogen, rotavap, installation
Hydrogen Device System Setup
After a successful setup, your condensation system should look like the image below.
Condenser
Clamp
Vacuum Port
Vapor Hose
Rotavap Adapter
Condenser
Glass Body
Pinch Clamp
Receiving
Flask
Power Switch
Condenser
Controller
Use and Disclosure of Data: Information contained herein is classified
as EAR99 under the U.S. Export Administration Regulations.
Export, reexport or diversion contrary to U.S. law is prohibited.
Evaporator Flask
Water Bath
Touch Screen
Controller
