U S E R M A N U A L
Series X - Maritime Multi Computer (MMC) Models
HD 12T21 MMC-xxx-xxxx - 12.1 inch Maritime Multi Computer
HD 15T21 MMC-xxx-xxxx - 15.0 inch Maritime Multi Computer
HD 17T21 MxC-xxx-xxxx - 17.0 inch Maritime Multi Computer
HD 19T21 MxC-xxx-xxxx - 19.0 inch Maritime Multi Computer
HD 24T21 MxC-xxx-xxxx - 24.0 inch Maritime Multi Computer
Tel: (+47) 4814 2200 - mail@hatteland-display.com - www.hatteland-display.com
Please visit www.hatteland-display.com for the latest electronic version of this manual.
Hatteland Display AS, Åmsosen, N-5578 Nedre Vats, Norway
User Manual MMC Series X
Updated: 06 Dec 2011
Doc Id: INB100485-1 (Rev 1)
Created: 363
Approved: 6542

Advertisement

Table of Contents
loading

Summary of Contents for Hatteland X Series

  • Page 1 Updated: 06 Dec 2011 Doc Id: INB100485-1 (Rev 1) Created: 363 Approved: 6542 Please visit www.hatteland-display.com for the latest electronic version of this manual. Hatteland Display AS, Åmsosen, N-5578 Nedre Vats, Norway Tel: (+47) 4814 2200 - mail@hatteland-display.com - www.hatteland-display.com...
  • Page 2 Information in this manual is copyrighted to the respective owners. All rights are reserved by Hatteland Display AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form without the prior written consent of Hatteland Display AS.
  • Page 3: Table Of Contents

    Contents Contents ..................3 Contents of package ..................5 General .................... 7 About this manual ..................8 About Hatteland Display ................8 www.hatteland-display.com ................8 Contact Information ..................8 Maritime Multi Computer (MMC) - Introduction ..........9 Product Labeling (examples) ..............10 Labels and Locations ..............10 Typenumber Structure ..............10 Warranty Label ................10...
  • Page 4 Contents Technical Drawings ..............27 Technical Drawings - HD 12T21 MMC-xxx-xxxx ........28 Standard Version ................28 Technical Drawings - HD 15T21 MMC-xxx-xxxx ........29 Standard Version ................29 Technical Drawings - HD 17T21 MxC-xxx-xxxx ........30 Standard Version ................30 Technical Drawings - HD 19T21 MxC-xxx-xxxx ........31 Standard Version ................31 Technical Drawings - HD 24T21 MxC-xxx-xxxx ........32 Standard Version ................32...
  • Page 5: Contents Of Package

    Package may also include: Item Description Illustration 4 pcs of housing, 2pin 1827732 MC 1,5/5-STF-3,81 to be used with the factory installed Hatteland Display COM NMEA or CAN modules (option dependent). Right side view Front view 1827732 INB100485-1 (Rev 1)
  • Page 6 This page left intentionally blank INB100485-1 (Rev 1)
  • Page 7: General

    General INB100485-1 (Rev 1)
  • Page 8: About This Manual

    About Hatteland Display Hatteland Display is the leading technology provider of specialized display and computer products, delivering high quality, unique and customized solutions to the international maritime, naval and industrial markets.
  • Page 9: Maritime Multi Computer (Mmc) - Introduction

    Series X on the maritime market. The considerable advances made by Hatteland Display over recent years in PC platform development is now enhancing further the panel PC offering. All Series X display sizes are available with state of the art PC technology integrated, designed and built for type approved maritime systems.
  • Page 10: Product Labeling (Examples)

    IND100780-4 - Rev 03 - 29 Sep 2011 Product Type Manufacturer & Country This document explains the type number structure for the Hatteland Display Series X Maritime Multi Computer product range. - Example standard typenumber HD 19T21 MMC-M1A-AAAA Input Voltages & Power Rating...
  • Page 11: Installation

    Installation INB100485-1 (Rev 1)
  • Page 12: Installation And Mounting

    General Installation Recommendations Installation and mounting 1. Most of our products are intended for various methods of installation or mounting (panel mounting, bracket mounting, ceiling/wall, console mounting etc.); for details, please see the relevant mechanical drawings. 2. Adequate ventilation is a necessary prerequisite for the life of the product. The air inlet and outlet openings must definitely be kept clear;...
  • Page 13: Ergonomics

    9. The classification is only valid for approved mounting brackets provided by Hatteland Display. The unit shall be mounted stand-alone without any devices or loose parts placed at or nearby the unit. Any other type of mounting might require test and re-classification.
  • Page 14: Cables

    General Installation Recommendations Cables Use only high quality shielded signal cables. Cable Entries & Connectors (Marked area) - Illustration only Bottom View Back View Maximum Cable Length Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal cable length will depend on the signal resolution and frequency, but also on the quality of the signal output from the computer/radar.
  • Page 15: Physical Connections - Mxc Based Units

    Physical Connections - MxC based units Connection area of unit (illustration) Removable Storage Trays PS/2 Keyboard/Mouse in DVI/RGB out Mic In/ Line Out Power Inputs DC & AC RJ45 Network Grounding Screw RGB/VGA out COM1, COM2 USB 1,2,3,4 Cable Tension To reduce tension of the cables you connect, secure them with a cable tie to the available chassis hinges located near the connectors.
  • Page 16 Physical Connections - MxC based units DVI-I or RGB / VGA OUT: Enables a direct clone signal output from the computer. You may choose to use a DVI-I 29P cable directly or use a DVI-I -> RGB adapter to use a RGB/VGA HD D-SUB 15P instead for this purpose. Connect the cable to the Connector (female) and secure it to the hex spacers provided on the unit.
  • Page 17: Operation

    Operation MMC Products INB100485-1 (Rev 1)
  • Page 18: User Controls

    Used to sense level of ambient light in the surrounding environment. The sensor data can be read by suitable software through the Hatteland Display SCOM functionality of the unit and thus can be used to control brightness remotely. Note: This sensor is not visible for the eye or has any illumination behind to indicate it’s position. Further, by touching or covering this area will naturally make the sensor data inaccurate.
  • Page 19 User Controls Power ON/OFF: This symbol and all text will illuminate in red when suitable power is connected and the unit is turned off. When the unit is on and operating, this symbol will change into green color and illuminate constantly. Power ON: To turn the unit on, verify that the symbol is illuminated in red (indicates suitable power is connected) and touch the power symbol and hold until the the symbol changes to green light or a image appears on the screen.
  • Page 20 This page left intentionally blank INB100485-1 (Rev 1)
  • Page 21: Specifications

    Specifications INB100485-1 (Rev 1)
  • Page 22: Specifications - Hd 12T21 Mmc-Xxx-Xxxx

    Power Consumption: • Operating : 60 W (max) TBC For a full overview of typenumbers, please review the following link: www.hatteland-display.com/pdflink/ind100780-4.php Compass Safe Distance: HD 12T21 MMC-xxx-xxxx Standard: TBD Steering: TBD MTBF (Mean Time Between Failures - MIL-HDBK-217 GB 25ºC) = TBD hours A P P R O V A L S &...
  • Page 23: Specifications - Hd 15T21 Mmc-Xxx-Xxxx

    • CAN module, 2 x CAN isolated Power Consumption: • Operating AC/DC : 60 W (max) TBC For a full overview of typenumbers, please review the following link: www.hatteland-display.com/pdflink/ind100780-4.php Compass Safe Distance: HD 15T21 MMC-xxx-xxxx Standard: TBD Steering: TBD MTBF (Mean Time Between Failures - MIL-HDBK-217 GB 25ºC) = TBD hours A P P R O V A L S &...
  • Page 24: Specifications - Hd 17T21 Mxc-Xxx-Xxxx

    • CAN module, 2 x CAN isolated Power Consumption: • Operating AC/DC : 60 W (max) TBC For a full overview of typenumbers, please review the following link: www.hatteland-display.com/pdflink/ind100780-4.php Compass Safe Distance: HD 17T21 MMC-xxx-xxxx Standard: TBD Steering: TBD MTBF (Mean Time Between Failures - MIL-HDBK-217 GB 25ºC) = TBD hours A P P R O V A L S &...
  • Page 25: Specifications - Hd 19T21 Mxc-Xxx-Xxxx

    • CAN module, 2 x CAN isolated Power Consumption: • Operating AC/DC : 125 W (max) TBC For a full overview of typenumbers, please review the following link: www.hatteland-display.com/pdflink/ind100780-4.php Compass Safe Distance: HD 19T21 MMC-xxx-xxxx Standard: TBD Steering: TBD MTBF (Mean Time Between Failures - MIL-HDBK-217 GB 25ºC) = TBD hours A P P R O V A L S &...
  • Page 26: Specifications - Hd 24T21 Mxc-Xxx-Xxxx

    Power Consumption: • Operating AC/DC : 125 W (max) TBC : TBD (typ) at max backlight+high CPU load For a full overview of typenumbers, please review the following link: www.hatteland-display.com/pdflink/ind100780-4.php Compass Safe Distance: HD 24T21 MxC-xxx-xxxx Standard: TBD Steering: TBD MTBF (Mean Time Between Failures - MIL-HDBK-217 GB 25ºC) = TBD hours...
  • Page 27: Technical Drawings

    Technical Drawings INB100485-1 (Rev 1)
  • Page 28: Technical Drawings - Hd 12T21 Mmc-Xxx-Xxxx

    Technical Drawings - HD 12T21 MMC-xxx-xxxx Standard Version INB100485-1 (Rev 1) IND100132-211...
  • Page 29: Technical Drawings - Hd 15T21 Mmc-Xxx-Xxxx

    Technical Drawings - HD 15T21 MMC-xxx-xxxx Standard Version INB100485-1 (Rev 1) IND100132-210...
  • Page 30: Technical Drawings - Hd 17T21 Mxc-Xxx-Xxxx

    Technical Drawings - HD 17T21 MxC-xxx-xxxx Standard Version INB100485-1 (Rev 1) IND100132-209...
  • Page 31: Technical Drawings - Hd 19T21 Mxc-Xxx-Xxxx

    Technical Drawings - HD 19T21 MxC-xxx-xxxx Standard Version INB100485-1 (Rev 1) IND100132-212...
  • Page 32: Technical Drawings - Hd 24T21 Mxc-Xxx-Xxxx

    Technical Drawings - HD 24T21 MxC-xxx-xxxx Standard Version INB100485-1 (Rev 1) IND100132-207...
  • Page 33: Technical Drawings - Accessories

    Technical Drawings - Accessories INB100485-1 (Rev 1)
  • Page 34: Mounting Brackets 24

    Technical Drawings - Accessories Mounting Brackets 24” INB100485-1 (Rev 1) IND100132-208...
  • Page 35: Console/Panel Mounting 24

    Technical Drawings - Accessories Console/Panel Mounting 24” INB100485-1 (Rev 1) IND100132-208...
  • Page 36: Flush Mounting 24

    Technical Drawings - Accessories Flush Mounting 24” INB100485-1 (Rev 1) IND100132-208...
  • Page 37: Appendixes

    Appendixes INB100485-1 (Rev 1)
  • Page 38: Pin Assignments - Common Connectors

    Pin 09 - RI Ring Indicate Note: The table above lists commonly-used RS-232 signals and pin assignments, however Serial Communication for Hatteland Display products may vary from product to product to support different end user systems. Appendix INB100485-1 (Rev 1)
  • Page 39 Pin Assignments - Common Connectors Pin Assignments - 24P DVI-D & DVI-I 1 2 3 4 5 6 7 8 C1 C2 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 C3 C4 Pin 01 T.M.D.S.
  • Page 40: Basic Trouble-Shooting

    Basic Trouble-shooting GENERAL ISSUES FOR TFT PANEL BASED PRODUCTS Note: Applies for a range of various products. This is only suitable for general guidance. O PICTURE / LED BEHAVIOUR: If there is no light at all in the LED at the FRONT, check power cables. If the LED in front is green then check if the brightness knob is turned to the right (max brightness).
  • Page 41: Declaration Of Conformity

    Declaration of Conformity We, manufacturer Hatteland Display AS Åmsosen, N-5578 Nedre Vats, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD, HM MIL, HM CMD, HT STD, HD MMD, HM MMD, HT MMC and HD MMC product ranges is in conformity with the following standards in accordance with the EMC Directive.
  • Page 42: Return Of Goods Information

    Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Display referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaulation or products subject for credit, you must ensure that all accessories received from our warehouse is returned.
  • Page 43: Terms

    Goods are considered delivered to customer when handed over to charterer. 8) FREIGHT / PACKING / FORWARDING FEE Hatteland Display AS charge NOK 50,- in forwarding fee for orders below NOK 1000,-. Freight charge according to expenses for orders above NOK 1000,-. VAT not included.
  • Page 44 Terms 12) CANCELLATION / RETURN Binding sales contract is concluded when we have confirmed customer’s purchase order. Any disagreements in our order confirmation must be reported to seller within 6 days. The agreement can not be altered without our permission, after acceptance from our supplier.
  • Page 45: Pixel Defect Policy

    TFT display. Neither the production at LCD-supplier nor the use of a LCD-Monitor after shipment can be influenced by Hatteland Display. Hence Hatteland Display cannot be made responsible for such dot failures.
  • Page 46: Notes

    Notes General Notes: (For all products) - The unit is type approved according to EN60945 4 th , 4.4, equipment category b) protected from the weather. - Other type approvals applies for the different products. Please see the appropriate “Specifications” page in this manual for more information. - Use of brillance and Glass Display Control™...
  • Page 47: Revision History

    Revision History Rev. Date Notes 08 Nov 2011 Release for internal review. 23 Nov 2011 Revised after internal review. 06 Dec 2011 Released for internet/customers Appendix INB100485-1 (Rev 1) IND100077-111...
