U S E R M A N U A L
Series 1 - Maritime Multi Computer Models
JH 15T17 MMC-xxx-Axxx - 15.0 inch Maritime Multi Computer
JH 15T17 MMC-xxx-Axxx - 15.0 inch Maritime Multi Computer (LED version)
JH 19T14 MMC-xxx-Axxx - 19.0 inch Maritime Multi Computer
JH 19T14 MMC-xxx-Axxx - 19.0 inch Maritime Multi Computer (LED version)
Please visit www.hatteland-display.com for the latest electronic version of this manual.
Hatteland Display AS, Stokkastrandvegen 87B, N-5578 Nedre Vats, Norway
Tel: (+47) 4814 2200 - mail@hatteland-display.com - www.hatteland-display.com
User Manual MMC Series 1
Updated: 09 Apr 2015
Doc Id: INB100216-1 (Rev 13)
Created: 363
Approved: 6405

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JH 15T17 MMC series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hatteland JH 15T17 MMC series

  • Page 1 Updated: 09 Apr 2015 Doc Id: INB100216-1 (Rev 13) Created: 363 Approved: 6405 Please visit www.hatteland-display.com for the latest electronic version of this manual. Hatteland Display AS, Stokkastrandvegen 87B, N-5578 Nedre Vats, Norway Tel: (+47) 4814 2200 - mail@hatteland-display.com - www.hatteland-display.com...
  • Page 2 Copyright © 2015 Hatteland Display AS Stokkastrandvegen 87B, N-5578 Nedre Vats, Norway. All rights are reserved by Hatteland Display AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Display AS.
  • Page 3: Table Of Contents

    Contents ..................3 Contents of package ..................5 General .................... 7 About this manual ....................8 About Hatteland Display ..................8 www.hatteland-display.com ................8 Contact Information ................... 8 Maritime Multi Computer (MMC) - Introduction ..........9 Basic Construction ................... 10 Product Labeling ....................11...
  • Page 4 Contents Technical Drawings ..............35 Technical Drawings - JH 15T17 MMC-xxx-Axxx ..........36 Standard Version ..................36 Technical Drawings - JH 19T14 MMC-xxx-Axxx ..........37 Standard Version ..................37 Technical Drawings - Accessories ..........39 Sun Visor - 15” ....................40 Sun Visor - 19”...
  • Page 5: Contents Of Package

    Contents of package Item Description Illustration 1 pcs of power cable European Type F “Schuko” to IEC. EUR TYPE F Length 1.8m Note: Included in package for models with AC input. FS-CABLE EU 1 pcs of power cable US Type B plug to IEC. US TYPE B Length 1.8m Note: Included in package for models with AC input.
  • Page 6 This page left intentionally blank...
  • Page 7: General

    General...
  • Page 8: About This Manual

    About Hatteland Display Hatteland Display is the leading technology provider of specialized display and computer products, delivering high quality, unique and customized solutions to the international maritime, naval and industrial markets.
  • Page 9: Maritime Multi Computer (Mmc) - Introduction

    ECDIS software through to engine monitoring and automation applications. It has power to spare too, so software developers can be sure that Hatteland Display Series 1 panel computers can handle the latest applications being designed for bridge and engine room systems in addition to other, more custom uses.
  • Page 10: Basic Construction

    Basic Construction Basic Construction - Series 1 Touch Screen (option) Sun Visor (option) Centerbox Water Cover (option) Mounting Bracket (option) Mechanics Glass Casing Rotary Bracket (option) Front Frame Bonding Electronics / PCB’s User Controls Logo label (option) Example with mounting bracket Example with sun visor, mounting bracket and rotary bracket General IND100077-75...
  • Page 11: Product Labeling

    This section details the locations, content details and specifications for factory mounted labels for all currently available standard Hatteland Display Maritime Multi Computer (MMC) - Series 1 models. This information will in most cases also apply for most Customized Models as well, but may differ based on customer requirements, in that case, please refer to the customized User Manual (paper or electronic version, dependent on customer requirements).
  • Page 12: Label Locations

    Product Labeling Label Locations Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below is seen from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation vs product size is drawn in.
  • Page 13: Warranty Label

    Date: 20110526 Serial Number: IND100780-2 - Rev 04 - 29 This document explains the type number structure for the Hatteland Display Series 1 Maritime Multi Computer product range JH 19T14 MMC-AA1-AAAA-000256 Barcode (TYP+SNO) Type+Serial Number - Example standard typenumber: JH 19T14 MMC-AA1-AAAA - Example standard description: 19.0”...
  • Page 14: Front Hatch Logo Label

    Front Hatch Logo Label The Hatteland Display MMC front frame design offers an area for customized logo hatch label. This hatch/label can be ordered and customized with your own logo delivered from us. The hatch is IP66 rated to protect the front mounted connector(s) behind the hatch.
  • Page 15: Touch Screen Products

    Introduction to products with touch screen Both Resistive and Capacitive touch screen solutions are used for our products. Please review specifications found in this manual or our website (www.hatteland-display.com) to find your exact type number and then determine if it uses Resistive or Capacitive.
  • Page 16: Touch Screen Drivers And Documentation

    All units are shipped with a Documentation and Drivers DVD or CD which contains suitable drivers for touch screens. (Named MEDIA STD01). You can also visit our website www.hatteland-display.com to view the same list (or even recently new added products) for our models with touch screen.
  • Page 17: Installation

    Installation...
  • Page 18: Installation And Mounting

    General Installation Recommendations Installation and mounting 1. Most of our products are intended for various methods of installation or mounting (panel mounting, bracket mounting, ceiling/wall mounting etc.); for details, please see the relevant mechanical drawings. 2. Adequate ventilation is a necessary prerequisite for the life of the product. The air inlet and outlet openings must definitely be kept clear;...
  • Page 19: Ergonomics

    9. The classification is only valid for approved mounting brackets provided by Hatteland Display. The unit shall be mounted stand-alone without any devices or loose parts placed at or nearby the unit. Any other type of mounting might require test and re-classification.
  • Page 20: Cables

    General Installation Recommendations Cables Use only high quality shielded signal cables. Cable Entries & Connectors (Marked area) - Illustration only Bottom View Back View Maximum Cable Length Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal cable length will depend on the signal resolution and frequency, but also on the quality of the signal output from the computer/radar.
  • Page 21: Rotary Bracket And Mounting Bracket (15 Inch) Combined Assembling

    General Installation Recommendations Rotary Bracket and Mounting Bracket (15 inch) combined assembling Illustration shows “Mounting Bracket JH 15TBR STD-A1” and “Rotary Bracket JH 15TRO STD-A1 (15 inch only)” combined. Both brackets are available separately and are delivered as such. Both brackets contains several parts (as indicated).
  • Page 22: Rotary Bracket And Mounting Bracket (17-26 Inch) Combined Assembling

    General Installation Recommendations Rotary Bracket and Mounting Bracket (17-26 inch) combined assembling Illustration below shows “Mounting Bracket” and “Rotary Bracket JH MMDRO STD-A1 (17 to 26 inch)” combined. Both brackets are available separately and are delivered as such. Both brackets contains several parts (as indicated). The table below illustrates a complete mounting of these two and you have to disassemble the “Mounting Bracket”...
  • Page 23: Physical Connections - Mmc / Xxc Based Units

    Physical Connections - MMC / xxC based units Connection area of unit (illustration) + internal miniPCI slot Parallel (LPT) PS/2 Mouse PS/2 Keyboard USB 2,3,4,5 COM1, COM2 2 x GigaBit LAN DVI-I/RGB OUT Compact Flash Reader Power Input AC or DC Grounding Screw: Please review “General Installation Chapter”, pt.
  • Page 24: Pci Slot

    Physical Connections - MMC / xxC based units DVI-I OUT: DVI/RGB OUT enables a direct clone signal output from the computer. You may choose to use a DVI-I 29P cable directly or use a DVI-I -> RGB adapter to use a RGB/VGA HD D-SUB 15P instead for this purpose. Connect the cable to the Connector (female) and secure it to the hex spacers provided on the unit.
  • Page 25: Operation

    Operation MMC Products...
  • Page 26: User Controls

    User Controls USER CONTROLS OVERVIEW The units are available as two different factory user control configurations illustrated below. Buzzer Potmeter Keypad w/Status LED ring #1: Potmeter, Buzzer and Keypad Control with its Status LED Ring. Brightness for the unit is adjusted by turning the potmeter clockwise or anti-clockwise.
  • Page 27 User Controls KEYPAD FUNCTIONALITIES (unit model dependable) Not in use Power button Left button Right button Push Buttons Status LED Ring Not in use MENU/POWER ICON function as: Power On/Off. Note: MENU OSD is not available on MMC units. LEFT (◄) function as: Decrease Brightness.
  • Page 28: Status Led Overview

    Status LED Overview Status LED Overview The unit features a multi purpose indicator LED status ring which through different patterns and realtime activity gives back the status of the signal detected, power on/off, calibration, menu activity and more. The LEDs are multicolored which either illuminate green or red, based on the activity. OFF (No power connected) OFF (Standby, power detected) ON (Signal Search)
  • Page 29: Specifications

    Specifications...
  • Page 30: Specifications - Jh 15T17 Mmc-Xxx-Axxx (Ccfl Version)

    Specifications - JH 15T17 MMC-xxx-Axxx (CCFL version) SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. All specifications are subject to change without prior notice! TFT Technology: Physical Dimensions: •...
  • Page 31: Specifications - Jh 15T17 Mmc-Xxx-Axxx (Led Version)

    Specifications - JH 15T17 MMC-xxx-Axxx (LED version) SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. All specifications are subject to change without prior notice! TFT Technology: Physical Dimensions: •...
  • Page 32: Specifications - Jh 19T14 Mmc-Xxx-Axxx (Ccfl Version)

    Specifications - JH 19T14 MMC-xxx-Axxx (CCFL version) SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: •...
  • Page 33: Specifications - Jh 19T14 Mmc-Xxx-Axxx (Led Version)

    Specifications - JH 19T14 MMC-xxx-Axxx (LED version) SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. All specifications are subject to change without prior notice! TFT Technology: Physical Considerations: •...
  • Page 34 This page left intentionally blank...
  • Page 35: Technical Drawings

    Technical Drawings...
  • Page 36: Technical Drawings - Jh 15T17 Mmc-Xxx-Axxx

    Technical Drawings - JH 15T17 MMC-xxx-Axxx Standard Version IND100132-172...
  • Page 37: Technical Drawings - Jh 19T14 Mmc-Xxx-Axxx

    Technical Drawings - JH 19T14 MMC-xxx-Axxx Standard Version IND100132-173...
  • Page 38 This page left intentionally blank...
  • Page 39: Technical Drawings - Accessories

    Technical Drawings - Accessories...
  • Page 40: Sun Visor - 15

    Technical Drawings - Accessories Sun Visor - 15” IND100132-109...
  • Page 41: Sun Visor - 19

    Technical Drawings - Accessories Sun Visor - 19” IND100132-67...
  • Page 42: Rotary Bracket - 15

    Technical Drawings - Accessories Rotary Bracket - 15” IND100132-148...
  • Page 43: Rotary Bracket - 17" To 26

    Technical Drawings - Accessories Rotary Bracket - 17” to 26” IND100132-46...
  • Page 44: Bracket - 15

    Technical Drawings - Accessories Bracket - 15” IND100132-167...
  • Page 45: En60945 Bracket - 19

    Technical Drawings - Accessories EN60945 Bracket - 19” IND100132-165...
  • Page 46: Rack Adapter - 15" Tft To 19

    Technical Drawings - Accessories RACK Adapter - 15” TFT to 19” IND100132-43...
  • Page 47: Crt Adapter - 15" Tft To 17

    Technical Drawings - Accessories CRT Adapter - 15” TFT to 17” IND100132-137...
  • Page 48: Crt Adapter - 19" Tft To 21

    Technical Drawings - Accessories CRT Adapter - 19” TFT to 21” IND100132-44...
  • Page 49: Crt Adapter Custom - 19" Tft To 21

    Technical Drawings - Accessories CRT Adapter Custom - 19” TFT to 21” IND100132-187...
  • Page 50: Vesa Bracket - 15

    Technical Drawings - Accessories VESA Bracket - 15” IND100132-113...
  • Page 51: Vesa Bracket - 19

    Technical Drawings - Accessories VESA Bracket - 19” IND100132-45...
  • Page 52: Water Cover - 15

    Technical Drawings - Accessories Water Cover - 15” IND100132-117...
  • Page 53: Water Cover - 19" (Hw01)

    Technical Drawings - Accessories Water Cover - 19” (HW01) IND100132-136...
  • Page 54 This page left intentionally blank...
  • Page 55: Appendixes

    Appendixes...
  • Page 56: Pinout Assignments - Common Connectors

    Pin 09 - RI Ring Indicate Note: The table above lists commonly-used RS-232 signals and pin assignments, however Serial Communication for Hatteland Display products may vary from product to product to support different end user systems. Please check additional pin assignments section in this manual for specific RS-232/RS-422/RS-485 pin assignments for your exact product.
  • Page 57 Pinout Assignments - Common Connectors 25P Parallel 13 12 11 10 9 8 7 6 5 4 3 2 1 25 24 23 22 21 20 19 18 17 16 15 14 Pin 01 - STROBE This signal indicates to the printer that data at PD7..0 are valid. Pin 02 - DATA0 Parallel data bus from PC board to printer.
  • Page 58 Pin Assignments - Common Connectors (Additional) Pin Assignments - 9P Serial COM RS-485/RS-422 Pin Assignments - 9P Serial COM RS-485/RS-422 Full Duplex Mode Half Duplex Mode 4 3 2 1 4 3 2 1 9 8 7 6 9 8 7 6 Pin 01 - N/C Not Connected Pin 01 - N/C...
  • Page 59: Basic Trouble-Shooting

    Basic Trouble-shooting GENERAL ISSUES FOR TFT PANEL BASED PRODUCTS Note: Applies for a range of various products. This is only meant as a general guide. O PICTURE / LED BEHAVIOUR: If there is no light at all in the LED at the FRONT, check power cables. If the LED in front is green then check if the brightness is set/adjusted to max brightness.
  • Page 60: Declaration Of Conformity

    Declaration of Conformity We, manufacturer, Hatteland Display AS, Stokkastrandvegen 87B, N-5578 Nedre Vats, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD, HM MIL, HM CMD, HT STD, HD MMD, HM MMD, HT MMC, HD MMC and HT/HM (computers) product ranges is in conformity with the following standards in accordance with the EMC Directive.
  • Page 61: Return Of Goods Information

    Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Display referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaulation or products subject for credit, you must ensure that all accessories received from our warehouse is returned.
  • Page 62: General Terms And Conditions

    General Terms and Conditions As of January 2015, Hatteland Display AS’ “Terms of Sales and Delivery” and “Warranty Terms” has been substituted by the updated ”General terms and conditions for sale of goods and performance of additional services” (the “General Terms and Conditions”).
  • Page 63: Pixel Defect Policy

    TFT display. Neither the production at LCD-supplier nor the use of a LCD-Monitor after shipment can be influenced by Hatteland Display. Hence Hatteland Display cannot be made responsible for such dot failures.
  • Page 64: Notes

    Notes General Notes: (For all products) - The unit is type approved according to EN60945 4 th , 4.4, equipment category b) protected from the weather. - Other type approvals applies for the different products. Please see Testing & Approvals Overview section in this manual for more information. - Use of brightness and push buttons may inhibit visibility of information at night.
  • Page 65: Revision History

    13 Nov 2012 Revised text and graphical layout as per. current Company Profile throughout the manual, page 1,8 and more. Added upgraded 15 inch spec., ref ECN: http://www.hatteland-display.com/mails/31_2011_ecn.html, page 29 Added upgraded 19 inch spec., ref ECN: http://www.hatteland-display.com/mails/02_2012_ecn.html, page 31...
