Installation - Tech Controllers Sinum EH-01 Quick Installation Manual

EN
- power supply ON
- device operation
- active LAN connection
- active WiFi connection
- active access to the Cloud service
1. Connect the power supply included in the set to the power socket in the Sinum central device.
2. Connect the Ethernet (network) cable and plug it into your home router.
3. The control light will indicate correct startup.
1. Connect the Sinum Central with the ethernet cable to a network device (router, switch)
2. Launch your web browser* and go to the website at https://search.sinum.tech. On this page, you need to
download the Windows/iOS/Linux PBX search application, so you can find the SINUM central device without
internet access. Alternatively, you can download the Sinum app on your phone to search for a Sinum central
device in your local network.
3. Select a new Sinum central device from the list of devices and click GO.
1. If there is no wired connection, to connect the Sinum Central device to the WiFi network, switch to the Access
Point mode by removing the upper part of the casing (fig.1) and pressing the button
on the back of the device once (fig.2).
2. Active Access Point mode is indicated by the steady blinking of the WiFi connection
control light.
3. Activate WiFi network search on your phone or computer.
4. Connect to the wireless network called „ap_sinum" or scan the QR code which, after
confirmation, will connect you to the network.
5. After connecting, a list of available WiFi networks will appear, which is downloaded once when the AccessPoint
mode is started in central device. To refresh the list of networks, restart the device in AccessPoint mode.
Optionally, you can enter the address "4.3.2.1" in your browser.
6. Select network, with which the Sinum Central device should connect.
7. Switch your computer / phone to the same WiFi network which your Sinum central device is connected to.
8. Launch your web browser* and go to https://search.sinum.tech. On this page, download the application for
finding SINUM central device for Windows/iOS/Linux, thanks to which you can find the device without access to
the Internet. Alternatively, you can download the Sinum app on your phone to search for a Sinum central device
in your local network.
9. After finding your Sinum central device, click GO.
Description of control lights

Installation

Configuration - using an ethernet cable
Configuration - via WiFi
- normal device operation
- service error
- recovery mode - emergency operation
- internal memory operation
- memory card operation
