ENGLISH (Original instructions)
If the battery pack does not charge properly:
u
Check operation of receptacle by plugging in a lamp
u
or other appliance;
Check to see if receptacle is connected to a light
u
switch which turns power off when you turn out
the lights;
Move the charger and battery pack to a location
u
where the surrounding air temperature is
approximately 18 °C – 24 °C;
If charging problems persist, take the tool, battery
u
pack and charger to your local service center.
The battery pack should be recharged when it fails to
u
produce sufficient power on jobs which were easily
done previously. DO NOT CONTINUE to use under these
conditions. Follow the charging procedure. You may also
charge a partially used pack whenever you desire with no
adverse effect on the battery pack.
Foreign materials of a conductive nature such as, but
u
not limited to, grinding dust, metal chips, steel wool,
aluminum foil, or any buildup of metallic particles
should be kept away from charger cavities. Unplug the
charger before attempting to clean.
Do not freeze or immerse the charger in water or any
u
other liquid.
Fitting and removing the battery (fig. C)
To fit the battery (10), line it up with the receptacle on the
u
tool. Slide the battery into the receptacle and push until
the battery snaps into place.
To remove the battery, push the battery release button
u
(10a) while at the same time pulling the battery out of the
receptacle.
Using the hedge trimmer attachment
Warning! Before assembly, make sure that the tool is
switched off and the battery is removed.
Installing and removing hedge trimmer attach-
ments. (fig D)
To fit an attachment or the extension pole to the base unit
u
(1), align the attachment base with the power head as
shown in figure D.
Firmly push the attachment or extension pole onto the
u
base unit until it snaps into place and an audible
click is heard.
Note: Attachments fit onto the extension pole in the same
manner as the base unit.
Ensure attachment is securely attached to the base unit or
u
extension pole by gently pulling it away. The attachment or
the extension pole should remain in place.
To remove an attachment, depress the release button (7)
u
located on the side of the attachment and pull attachment
away from the base unit or extension pole.
8
8
Note: Only use attachments that are specifically designed for
and are compatible with the power head.
Correct hand position (fig. E)
Base mode, proper hand position requires the left hand on the
bail handle (3), with the right hand on the main handle (2).
Switching on (fig. E, F)
Push the lock off switch ( 5 ) down. Squeeze the bail
u
handle (3) and then squeeze the ON/OFF switch (2). Once
the unit is running, you may release the lock off switch.
The more the ON/OFF is depressed, the higher the speed
of the base unit.
In order to keep the unit running you must continue to
u
squeeze both the bail handle and the ON/OFF. To turn the
unit off, release the ON/OFF switch or bail handle.
Trimming Instructions (fig. G, H, I, J, K)
Note: keep hands away from blades. Blade may coast after
turn off.
Working positions (fig E, F, G)
Maintain proper footing and balance and do not overreach.
Wear safety goggles, non-skid footwear when trimming. Hold
the unit firmly in both hands and turn the unit on.
Always hold the trimmer as shown in Figures E, F and G, with
one hand on the main handle (3) and one hand on the bail
handle (4). Never hold the unit by the hedge trimmer blade (8).
Trimming new growth (fig H)
Using a wide, sweeping motion, feeding the blade teeth
through the twigs, is most effective. A slight downward tilt of
the blade in the direction of motion gives the best cutting.
Level hedges (fig I)
To obtain exceptionally level hedges a piece of string can be
stretched along the length of the hedge as a guide.
Side trimming hedges (fig J, K)
Orient the trimmer as shown and begin at the bottom and
sweep up.
Note: The cutting blades are made from high quality,
hardened steel and with normal usage, they will not require
resharpening. However, if you accidentally hit a wire fence,
stones, glass, or other hard objects as shown in figure K, you
may put a nick in the blade. There is no need to remove this
nick as long as it does not interfere with the movement of the
blade. If it does interfere, remove the battery and use a fine
toothed file or sharpening stone to remove the nick. If you
drop the trimmer, carefully inspect it for damage. If the blade is
bent, housing cracked, handles broken or if you see any other
condition that may affect the trimmer's operation contact your
local BLACK+DECKER authorized service center for repairs
before putting it back into use.
Fertilizers and other garden chemicals contain agents which
greatly accelerate the corrosion of metals. Do not store the
unit on or adjacent to fertilizers or chemicals.
With the battery removed, use only mild soap and a damp
cloth to clean the unit. Never let any liquid get inside the unit;
never immerse any part of the unit into a liquid. Prevent the
blades from rusting by applying a film of light machine oil
after cleaning.

Troubleshooting

Problem Possible Cause Possible Solution
Unit will not Battery pack not installed Check battery pack
start. properly. installation
Battery pack not charged. Check battery pack
charging requirements.
Internal componets too hot. Allow tool to cool down.
Attachment or extension pole Ensure attachemnt is
not attached to the base unit. properly seated and locked
into position on the
extension pole.
Ensure extension pole is
properly seated and locked
into position on the base
unit.
Battery pack Battery pack not inserted into Insert battery pack into
will not charger. charger until LED
charge. illuminates.
Charger not plugged in. Plug charger into a working
outlet. Refer to "Important
charging notes" for more
details.
Surrounding air temperature Move charger and battery
too hot or too cold pack to a surrounding air
temperature of above 40
degrees F (4,5°C) or below
105 degrees F (+40,5°C)
Unit shuts off Battery pack has reached its Allow battery pack to cool
abruptly. maximum thermal limit. down.
Out of charge. (To maximize Place on charger and allow
the life of the battery pack it is to charge.
designed to shut off abruptly
when the charge is depleted.)

Maintenance

Your BLACK+DECKER appliance has been designed
to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends
upon proper care and regular cleaning.
Regularly clean the appliance using a damp cloth. Do not
u
use any abrasive or solvent-based cleaner. Never let any
liquid get inside the appliance and never immerse any part
of the appliance into liquid.
Protecting the environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.
(Original instructions) ENGLISH
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions.
Further information is available at www.2helpU.com
Technical data
BCASH81B (H1)
Input voltage V
DC
No load speed /min
Battery 90617054
Voltage V
DC
Capacity Ah
Type
Charger 90634972
Input Voltage V
AC
Output current A
Approx Charge Time min
Level of sound pressure according to EN 60745:
Sound pressure for Hedge trimmer (L ) 84.5 dB(A), uncertainty (K) 1.4 dB(A)
pA
accoustic power for Hedge trimmer (L ) 94.5 dB(A), uncertainty (K) 0.8 dB(A)
WA
Vibration total values (triax vector sum) according to EN 60745:
Hedge Trimmer (a ) 2.5 m/s , uncertainty (K) 1.5 m/s
2 2
h
EC declaration of conformity
%
MACHINERY DIRECTIVE
OUTDOOR NOISE DIRECTIVE
BCASH81B SEASONMASTER
TM
Hedge trimmer attachment
Black & Decker declares that these products described under
"technical data" are in compliance with:
EN 60745-1:2009+A11:2010, EN 60745-2-15:2009+A1:2010
These products also comply with Directive
2006/42/EC, 2014/30/EU and 2011/65/EU
Hedge trimmer, 2000/14/EC, Annex V
Measured sound power level (LwA) 95 dB(A)
Guaranteed sound power (LwA) 101 dB(A)
18
0-1900
18
2
Li-Ion
230
1
120
