- Page 1 BFC-1232 12.1" 6th Gen Intel® Core™ SoCFanless Full Flat Multi-Touch Panel PC with Front IP-65 Quick Reference Guide Ed –11 May 2021 Copyright Notice Copyright 2021 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017B221A0R...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 BFC-1232 Quick Reference Guide...
-
Page 3: Table Of Contents
System Dimensions ....................8 Hardware Configuration ..................... 9 BFC-1232 connector mapping ................10 2.1.1 Serial port 3/4 connector (COM1/2) ................... 10 2.1.2 Serial port 5 connector (COM4) ....................10 Installing Hard Disk & Memory (BFC-1232) ............11 BFC-1232 Quick Reference Guide... -
Page 4: Getting Started
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. 1.2 Packing List 1 x BFC-1232 Panel PC 4 BFC-1232 Quick Reference Guide... -
Page 5: System Specifications
Mechanical Power Type AT/ATX Lockable DC in Power Connector Type (Option with 2-pin power connector) Demension 292.86 x 225.4 x 49 mm Weight 3.8 Kg Color Silver Aluminum, Black Metal BFC-1232 Quick Reference Guide... - Page 6 ISTA 2A, IEC-60068-2-32 Test:Ed Operating Temperature 0°C ~ 40°C (32°F ~ 104°F) Operating Humidity 40°C@ Relative Humidity, Non-condensing Storage Temperature -10°C ~ 50°C (14°F ~ 122°F) Note: Specifications are subject to change without notice. 6 BFC-1232 Quick Reference Guide...
-
Page 7: System Overview
DB-9 male connector HDMI HDMI connector LAN1/2 RJ-45 Ethernet 1/2 Power 2 pin Power connector DC IN DC Power-in connector RESET Reset button HDD LED Power LED USB 2.0 connector x 2 USB 3.0 connector x 4 BFC-1232 Quick Reference Guide... -
Page 8: System Dimensions
BFC-1232 1.5 System Dimensions (Unit: mm) 8 BFC-1232 Quick Reference Guide... -
Page 9: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration For advanced information, please refer to: 1- EBM-SKLU User’s Manual Note: If you need more information, please visit our website: http://www.avalue.com.tw BFC-1232 Quick Reference Guide... -
Page 10: Bfc-1232 Connector Mapping
DTR# COM2 is connect from COM4 pin header at motherboard. 2.1.2 Serial port 5 connector (COM4) Signal PIN PIN Signal DCD# DSR# RTS# Note: CTS# COM4 is connect from COM5 pin header at motherboard. DTR# 10 BFC-1232 Quick Reference Guide... -
Page 11: Installing Hard Disk & Memory (Bfc-1232)
Quick Reference Guide 2.2 Installing Hard Disk & Memory (BFC-1232) Step 1. Remove 6 screws to release the chassis cover, and remove it. Step 2. Remove 2 screws to release the HDD bracket. Step 3.1 Slide HDD into its bracket until properly seated.
