- Page 1 BFC-1509 ® 15” Intel Celeron SOC Processor J1900 Multifunctional Full Flat Multi-Touch Panel Computer Quick Reference Guide Ed –27 May 2016 Copyright Notice Copyright 2016 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017BF09A0R...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 BFC-1509 Quick Reference Guide...
-
Page 3: Table Of Contents
System Dimensions ....................8 1.5.1 Front, rear and side view ......................8 Hardware Configuration ................... 10 BFC-1509 connector mapping ................11 2.1.1 External Serial Port 1 connector (COM1) .................. 11 Installing Hard Disk & Memory (BFC-1509) ............12 BFC-1509 Quick Reference Guide... -
Page 4: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x BFC-1509 15” Multifunctional Full Flat Multi-Touch Panel Computer 1 x DVD-ROM contains the followings: ... -
Page 5: System Specifications
350mm x 273.9mm x 53.5mm Weight 4.2 Kg Color Front Silver & Rear panel Black Fanless Reliability EMI Test Class B Safety CE FCC Dust and Rain Test Front Panel IP65 BFC-1509 Quick Reference Guide... - Page 6 Drop Test Reference ISTA 2A, Method: IEC-60068-2-32 Operating Temperature 0 to 40°C Operating Humidity 5%~90% relative humidity, non-condensing Storage Temperature -10 to 50°C Note: Specifications are subject to change without notice. 6 BFC-1509 Quick Reference Guide...
-
Page 7: System Overview
DB-9 male connector HDMI HDMI connector LAN1/2 RJ-45 Ethernet 1/2 Power System power switch DC IN DC Power-in connector Reset button RESET HDD LED Power LED USB 2.0 connector x 1 USB 3.0 connector x 1 BFC-1509 Quick Reference Guide... -
Page 8: System Dimensions
BFC-1509 1.5 System Dimensions 1.5.1 Front, rear and side view 8 BFC-1509 Quick Reference Guide... - Page 9 Quick Reference Guide (Unit: mm) BFC-1509 Quick Reference Guide...
-
Page 10: Hardware Configuration
BFC-1509 2. Hardware Configuration For advanced information, please refer to: 1- EBM-BYT Quick Installation Guide or User’s Manual Note: If you need more information, please visit our website: http://www.avalue.com.tw 10 BFC-1509 Quick Reference Guide... -
Page 11: Bfc-1509 Connector Mapping
Quick Reference Guide 2.1 BFC-1509 connector mapping 2.1.1 External Serial Port 1 connector (COM1) Signal PIN PIN Signal NDCDA#_485TXN NDSRA# NRXDA_485TXP NRTSA# NTXDA_485RXP NCTSA# NDTRA#_485RXN NRIA# BFC-1509 Quick Reference Guide 11... -
Page 12: Installing Hard Disk & Memory (Bfc-1509)
BFC-1509 2.2 Installing Hard Disk & Memory (BFC-1509) Step1. Unfasten 6 screws from the case to take off the top chassis. Step2. Remove the top chassis. 12 BFC-1509 Quick Reference Guide... - Page 13 Quick Reference Guide Step3. Unfasten 4 screws of the HDD bracket and take it off. Step4. Remove the SODIMM from the memory socket. BFC-1509 Quick Reference Guide 13...
