Avalue Technology VNS-10WR2 Quick Reference Manual

10.1” ultra slim panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VNS-10WR2
10.1" Ultra Slim Panel PC
Quick Reference Guide
st
1
Ed – 08 March 2024
Copyright Notice
Copyright  2024 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017V109A0R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VNS-10WR2 and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology VNS-10WR2

Summary of Contents for Avalue Technology VNS-10WR2

  • Page 1 VNS-10WR2 10.1” Ultra Slim Panel PC Quick Reference Guide Ed – 08 March 2024 Copyright Notice Copyright  2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017V109A0R...
  • Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 VNS-10WR2 Quick Reference Guide...

  • Page 3: Table Of Contents

    Rear View ..........................9 1.5 System Dimensions ....................10 1.6 VESA Mounting ....................... 10 Hardware Configuration ..................14 2.1 VNS-10WR2 connector mapping ................15 2.1.1 Serial port connector (COM) ....................15 2.2 Cleaning and Disinfecting ..................16 LED Instruction ..................... 17 3.1 For Android 11 LED instruction ................

  • Page 4: Getting Started

    Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées selon les instructions 1.2 Packing List 1 x VNS-10WR2  1 x AC/DC adapter 12V/5A 90 Screw Type (Option)  1 x power cord (Option)  4 VNS-10WR2 Quick Reference Guide...
  • Page 5 Quick Reference Guide VNS-10WR2 Quick Reference Guide...

  • Page 6: System Specifications

    1.1kg Fanless OS Support Android 11, Debain 11 Reliability EMI Test CE, FCC Class B Air 8Kv / Contact 4Kv Sine Vibration test (Non-operation) Vibration Test Reference IEC60068-2-6 Testing procedures. Test Fc : Vibration sinusoidal 6 VNS-10WR2 Quick Reference Guide...
  • Page 7 1. One corner , three edges, six faces Drop Test 2. ISTA 2A, IEC-60068-2-32 Test:Ed Operating Temperature 0°C ~ 45°C Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Storage Temperature -10°C ~ 60°C Note: Specifications are subject to change without notice. VNS-10WR2 Quick Reference Guide...

  • Page 8: System Overview

    VNS-10WR2 1.4 System Overview 1.4.1 Front View Camera Back Brightness Volume Power Up/down Up/down on/off 8 VNS-10WR2 Quick Reference Guide...

  • Page 9: Rear View

    Quick Reference Guide 1.4.2 Rear View Connectors Label Function Note DC-IN power connector DC IN RJ-45 Ethernet Serial port connector 2 x USB 3.0 connector Line-out audio jack Line-out VNS-10WR2 Quick Reference Guide...

  • Page 10: System Dimensions

    VNS-10WR2 1.5 System Dimensions (Unit: mm) 1.6 VESA Mounting 10 VNS-10WR2 Quick Reference Guide...
  • Page 11 Quick Reference Guide Step1. Insert and fasten 4 screws on each side of VNS-10WR2 to secure VESA Mount. VNS-10WR2 Quick Reference Guide 11...
  • Page 12 VNS-10WR2 Step2. Insert and fasten 4 screws on each side of the monitor to secure VESA Mount. 12 VNS-10WR2 Quick Reference Guide...
  • Page 13 Quick Reference Guide Step3. Slide VNS-10WR2 onto the Monitor. VNS-10WR2 Quick Reference Guide 13...

  • Page 14: Hardware Configuration

    VNS-10WR2 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw 14 VNS-10WR2 Quick Reference Guide...

  • Page 15: Vns-10Wr2 Connector Mapping

    Quick Reference Guide 2.1 VNS-10WR2 connector mapping 2.1.1 Serial port connector (COM) RS-232 Signal RS-485 Signal DATA- DATA+ VNS-10WR2 Quick Reference Guide 15...

  • Page 16: Cleaning And Disinfecting

    VNS-10WR2 2.2 Cleaning and Disinfecting During normal use of VNS-10WR2, the device may become dirty and should be regularly cleaned. Cleaning Instructions 1. Turn off the computer before starting clean up. This way, you can see any dirt on the screen;...

  • Page 17: Led Instruction

    Quick Reference Guide 3. LED Instruction Note: If you need more information, please visit our website: http://www.avalue.com.tw VNS-10WR2 Quick Reference Guide 17...

  • Page 18: For Android 11 Led Instruction

    255, minimum is 0. A simple example to demonstrate how to trun LED ON/OFF show in next section. LED index Color File path /sys/class/leds/L3/brightness /sys/class/leds/L2/brightness /sys/class/leds/L1/brightness /sys/class/leds/L6/brightness /sys/class/leds/L5/brightness /sys/class/leds/L4/brightness /sys/class/leds/L9/brightness /sys/class/leds/L8/brightness /sys/class/leds/L7/brightness /sys/class/leds/L12/brightness /sys/class/leds/L11/brightness /sys/class/leds/L10/brightness /sys/class/leds/L15/brightness 18 VNS-10WR2 Quick Reference Guide...

  • Page 19: Example Of Led Control

    LED 1 should be ON and the color will be blue. sudo echo 200 > /sys/class/leds/L1/brightness step.3 type in below script, LED 1 should be OFF sudo echo 0 > /sys/class/leds/L1/brightness VNS-10WR2 Quick Reference Guide 19...
