Montageanleitung - ULF Universelles Ladesäulen Fundament
Installation instructions - ULF Universal charging station
foundation
Vor Beginn der Montage Anleitung lesen und gut aufbewahren!
Read the instructions prior to installation and keep them in a safe place!
www.hauff-technik.de
DE
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hauff-Technik ULF

  • Page 1 Montageanleitung - ULF Universelles Ladesäulen Fundament Installation instructions - ULF Universal charging station foundation Vor Beginn der Montage Anleitung lesen und gut aufbewahren! Read the instructions prior to installation and keep them in a safe place! www.hauff-technik.de...
  • Page 2 Universelles Ladesäulen Fundament 300/380/470 0,6-1 m 0,6-1 m 830 mm (5) 730 - 830 mm 730 mm (4) 830 mm Art. Nr.: 3030503545 Rev.: 01/2023-09-06...
  • Page 3 Universelles Ladesäulen Fundament Art. Nr.: 3030503545 Rev.: 01/2023-09-06...
  • Page 4 Folgeschäden keinerlei Gewährleistung über- tionsfristen geltend gemacht werden. nommen wird. Lieferumfang Das Universelles Ladesäulen Fundament ULF dient als Fundament zur Installation Zum Lieferumfang des Universellen Ladesäulen Fundaments gehören: von Ladesäulen und Stelen. Der Anschluss von Strom und Datenkabeln erfolgt über eine Leerrohrverbindung •...
  • Page 5 • Claims for damages can only be asserted within the applicable claim period. The Universal charging station foundation ULF serves as a foundation for the in- stallation of charging stations and pedestals. Connection of power and data ca- Scope of supply...
  • Page 6: Benötigtes Werkzeug Und Hilfsmittel

    ULF empfehlen wir bauseits Für die ordnungsgemäße Installation des Universellen La- ein Schnurgerüst vorzubereiten. Die Schnur be- desäulen Fundaments ULF wird neben dem üblichen Stan- stimmt die Ausrichtung bei mehreren Universel- dardwerkzeug folgendes Werkzeug, Hilfsmittel und Zube- len Ladesäulenfundamenten (siehe Abb.: 3). Bei hör benötigt:...
  • Page 7 (ggf. warten, bis der Beton gemäß Herstelleranga- Abb.: 3). ben ausgehärtet ist). ► In mehreren Lagen und sorgfältig verdichten. 6 ULF montieren ► Am Rand der Fundamentplatte sorgfältig unterstop- fen. Eine Ladesäule muss durch Schutzelemente wie z. Angefülltes Universelles Ladesäulenfundament ...
  • Page 8: Passendes Zubehör

    Universelles Ladesäulen Fundament 9 Installationsbeispiel Installationsbeispiel mit 2 Kabelschutzrohren Legende zu Abb.: 12 Kabelschutzrohr Datenkabel Datenkabel+Stromkabel Ladestele 10 Passendes Zubehör Artikel Artikelnummer Kabelschutzrohr 30m Rolle 3030401995 HAB ETGAR WR75 GR30000 ET- 30304492061 GAR Anschlussmuffe für Kabel- VE = 10 Stück schutzrohr ETGAR ANS 4x5-25 Manschettenstopfen für Elektro/Er- 50601507051...
  • Page 9: Publishing Notes

    For the correct installation of the Universal charging sta- the orientation of several universal charging sta- tion foundation ULF the following tools and aids are re- tion foundations (see Fig.: 3). When considering quired in addition to the usual standard tools:...
  • Page 10 Universal charging station foundation Compact the soil evenly and sufficiently (see Fig.: 3). Lean concrete foundation Top layer 6 Installing the ULF 7 Pull in cables Charging stations must be protected using pro- tective elements such as e.g. protective bar / bol- If necessary, use the pull-in aid and slide in from the lard / curb.
  • Page 11 Universal charging station foundation Article Article number HAB ETGAR WR75 GR30000 30304492061 ETGAR Connection sleeve for cable PU = 10 pieces duct ETGAR ANS 4x5-25 Sleeve cap for power/grounding 50601507051 and communication ETGAR MS75 K PU = 12 pieces 1x13-21+3x7-13+1x5-13 Service telephone + 49 7322 1333-0 Subject to change! Art.
  • Page 12 Notizen / N otes Hauff-Technik GmbH & Co. KG Robert-Bosch-Straße 9 89568 Hermaringen, GERMANY Tel. +49 7322 1333-0 Fax + 49 7322 1333-999 office@hauff-technik.de    www.hauff-technik.de...

This manual is also suitable for:

Ulf300Ulf380Ulf470
