- Page 1 Front page O P E R A T I N G I N S T R U C T I O N S Gas Cell AGK848 Installation Operation Maintenance...
- Page 2 Original Documents The English edition 8011793 of this document is an original docu- ment of SICK AG. SICK AG assumes no liability for the correctness of an unauthor- ized translation. Please contact the manufacturer or your local representative in case of doubt.
- Page 3 Risk or hazardous situation which could result in severe personal injury or death. CAUTION Hazard or unsafe practice which could result in less severe or minor injuries and/or property damage. Gas Cell AGK848 Operating Instructions 8011793/2012-07 (V 1.3) © SICK AG...
-
Page 4: Table Of Contents
Safety temperature switch has triggered ........30 Gas Cell AGK848 Operating Instructions V1.3 8011793 © SICK AG... - Page 5 Technical data ............. . 33 Gas Cell AGK848 Operating Instructions V 1.3 8011793 © SICK AG...
- Page 6 Contents Gas Cell AGK848 Operating Instructions V1.3 8011793 © SICK AG...
-
Page 7: Important Information
Important Information Gas Cell AGK848 Important Information Main hazards Intended use Own responsibility Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 8: Main Hazards
1. 3 Intended user The Gas Cell AGK848 may only be used by skilled persons who, based on their technical training and knowledge as well as knowledge of the relevant regulations, can assess the tasks given and recognize the hazards involved. - Page 9 Retention of documents These Operating Instructions: ▸ Must be available for reference. ▸ Must be passed on to new owners. ▸ Pay attention to the supplied documents. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG...
- Page 10 Important Information Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG...
-
Page 11: Product Description
Product Description Gas Cell AGK848 Product Description Product identification Functional principle Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 12: Product Identification
88709 Meersburg · Germany Functional principle 2. 2 The Gas Cell AGK848 serves to measure gaseous molecules absorbing in the IR wave- length range. It is intended exclusively for use on a Matrix-M cube (Bruker Optics Inc.). Fig. 1 Gas Cell AGK848 on Matrix-M cube... -
Page 13: Important Components
Mirror plate Sample gas outlet Input of Output of optical beam tube optical beam tube Purge air connection of optical beam tubes (at rear of cell) Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... - Page 14 Product Description Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG...
-
Page 15: Installation
Installation Gas Cell AGK848 Installation Installation Initial start-up Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 16: Safety Information For Installation
When cold sample gas is fed to a heated cell, it is possible that the meas-ure- ment signal becomes unstable due to thermal turbulences. ▸ Provide a suitable thermostatic control. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 17: Installation
The sample gas outlet may not increase the working pressure. ▸ Only use tubes and screw connections that are adequate for the required pressure. ▸ Do not bend or crimp the tubes. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 18: Performing The Leak Tightness Test
Heat the cell to nominal temperature before feeding gas (→ page 21, §4). Purge air connection 3. 4 ▸ Optional: Connect the purge air tube to the purge air connection of the optical beam tubes (→ page 18). Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 19: Electrical Installation
Connector type: COMBICON (PHOENIX CONTACT) (Operator-side connector → page 20, §3.5.3). Fig. 5 Connecting diagrams Note jumpers HP = heating cartridge 4 Connect the supply voltage. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 20: Installation Material (Optional)
● Operator-side connector parts set (Order number: 2041058, specify mains voltage). Contents: 2 plugs, cable, fitting panel. The 8-pole plug will then be configured for the mains voltage according to the order (→ page 19). Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 21: Start-Up / Operation
Start-up / Operation Gas Cell AGK848 Start-up / Operation Start-up Operation Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 22: Start-Up
– Maximum pressure: 200 kPa (2 bar) Set the sample gas flow: – Recommended flow: 300 - 400 l/h – Minimum flow 150 l/h – Maximum flow 400 l/h Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 23: Operation
When the safety temperature switch has switched off the cell, it is possible that the seals of the cell are damaged. ▸ Actions → page 30, §7.2. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... - Page 24 Start-up / Operation Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG...
-
Page 25: Shutdown
Shutdown Gas Cell AGK848 Shutdown Preparations Switch-off procedure Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 26: Shutdown
Dispose of parts that came into contact with media according to the hazardous waste regulations. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 27: Maintenance
Maintenance Gas Cell AGK848 Maintenance Maintenance plan Recommended spare parts Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 28: Maintenance Intervals
Maintenance kit windows and gaskets for cell 2045740 Maintenance kit gaskets GIU (Gas Inlet Unit) 2045739 [1] Number per maintenance interval (y=yearly, 2y=2 every two years) Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 29: Clearing Malfunctions
Clearing Malfunctions Gas Cell AGK848 Clearing Malfunctions General malfunctions Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 30: Clearing Malfunctions
▸ Perform a leak test (→ page 18, §3.3.3). ▸ If necessary, put the cell out of operation (→ page 25, §5) and contact SICK Service. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 31: Technical Specification
Technical Specification Gas Cell AGK848 Technical Specification Declaration of conformity Technical data Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 32: Conformity
● Electrical energy: The wiring system to the mains supply voltage of the system must be installed and fused according to the relevant regulations. Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... -
Page 33: Technical Data
Reset temperature: Approx. 205°C (400°F) Heating period: From room temperature to 180°C (350°F): Approx. 4 h Sintered metal filter: Pore width 10 m (400 Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG... - Page 34 Technical Specification Gas Cell AGK848 · Operating Instructions · 8011793 V 1.3 · © SICK AG...
