System Q NiteDevil CAM195L Manual

www.kovert.com
CAM195L
The CAM195L Traditional
NiteDevil
The NiteDevil Camera is a traditional style camera
for fitting in a standard housing. It produces high
quality images and works in extremely low light
conditions. The NiteDevil was originally developed
for bars and nightclubs but is also a good choice for
external dimly lit areas such as car parks and
compounds. This camera has many features including
a Sony CCD providing a resolution of 540 TVL, very
low light sensitivity down to 0.002Lux, electronic
iris, an OSD facility providing options for motion
detection, Digital Noise Reduction, privacy masking
and camera setup options. No need for additional
lighting with this camera. It is truly amazing.
Features
1/3" SONY SUPER HAD 540 TVL CCD -
Low power consumption -
Mirror function –
Privacy Masking –
DC Drive Lens (CCT342 2.8~12mm)
Use with CS-Mount or C-Mount lens -
Powering the Camera
The dome requires a 24v AC or 12v DC regulated power supply.
12v DC power
When connecting to 12v DC power always use a regulated supply. There is no polarity setting.
Use a 12v DC 500mA power supply unit minimum.
24v AC power
When connecting to 24v AC power supply there is no need to check AC' s power polarity.
Use a 24v AC 300mA power supply unit minimum.
Precautions
Do not install the camera in extreme temperature conditions. Only use the camera where temperatures are between –
10 degrees centigrade and +50 degrees centigrade.
Never install the camera in damp or humid conditions. This can affect image quality.
This camera requires stable lighting conditions to operate effectively.
Do not touch the front lens of the camera. Fingerprints can stain the lens glass.
The camera must not be placed directly facing the sun or strong light. This may damage the camera CCD.
Never expose the camera to rain or liquids. These will corrode the camera electronics.
Do not subject the camera to vibration as it may cause camera malfunctions.
Email: support@kovert.com
Traditional Style NiteDevil Camera with Lens
The CAM195L comes complete with a CCT342
fitted lens 2.8mm ~ 12mm Vari-focal Auto Iris
D/D
Low illumination down to 0.002 Lux -
12vDC 260mA or 24vAC at 170mA –
Day/Night mode –
Digital Noise Reduction –
Electronic Iris –
Motion Detect facility.
1
Doc XCAM195L
