Summary of Contents for Fieldmann FDV 2003-E
-
Page 1: Pictorial Appendix
FDV 2003 - E... -
Page 3: Table Of Contents
Contents Impact Drill INSTRUCTION MANUAL Thank you for your purchase of the impact drill. For your personal safety, read and understand the Instruction Manual before using. Keep the Instruction Manual in a safe place for future reference. CONTENTS PICTORIAL APPENDIX ............................3 1. -
Page 4: General Safety Instructions
WARNING! Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. Do not use the power tool in any of the following situations. FDV 2003-E... -
Page 5: Packaging
General safety instructions Keep the power tool out of reach of children. Store idle power tools in the original package in a safe place and out of reach of children. Disconnect the power cord from the power outlet before making any adjustments, changing accessories, or storing power tools. -
Page 6: Symbols
Symbols 2. SYMBOLS The product complies with the applicable standards and regulations. Read the Instruction Manual attentively prior to use. Double-insulated. Use eyes protective equipment Use ears protectiove equipment FDV 2003-E... -
Page 7: Machine Description And Items Delivered
Machine description and included contents | Putting into operation 3. MACHINE DESCRIPTION AND ITEMS DELIVERED Machine Description (see pic. 1) 1. ON/OFF switch 2. ON/OFF switch lock button 3. Rotary speed selector 4. Rotation direction selector 5. Drill 6. Standard/Impact drilling selector 7. -
Page 8: Appropriate Application
5. APPROPRIATE APPLICATION The FDV 2003-E tool is intended for impact drilling in bricks and concre and drilling in wood, metal, ceramics and plastics. The tools equipped with electronic controls and right/left rotation are also suitable for screwing and threading. -
Page 9: Technical Specifications
Adjustment and operation | Technical specifications Loosen the screw prior to chuck removal. To loosen the screw, turn it in a clockwise direction. The chuck can be equipped with all standard drills and extensions manufactured in compliance with the business standards up to dia. 13 mm. The power tool is fitted with the quick-release chuck to facilitate exchange of the extensions during manual drilling without a key. -
Page 10: Declaration Of Conformity
Declaration of conformity 8. DECLARATION OF CONFORMITY Product/Name: IMPACT DRILL / FIELDMANN Type/Model: FDV 2003 - E ........... 230V/50Hz/1 050W/0–1 100/0–2 800rpm/Ø13mm The product complies with the following directives: The Directive of the European Parliament and the Council No. 2006/95/EC dated 12 December 2006 on the harmonisation of the laws of Member States relating to electrical equipment designed for use within certain voltage limits. -
Page 11: Disposal
Disposal 9. DISPOSAL INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED PACKAGING Put any used package material to the place determined by the municipality for waste disposal. DISPOSAL OF USED ELECTRIC AND ELECTRONIC EQUIPMEN This symbol on products or accompanying documents means that used electric or electronic products must not be put to ordinary municipal waste. - Page 12 FDV 2003-E...
