*12 The number of connected peripheral devices differs according to the capacity. For details, refer to the FR-HC2 Instruction Manual.
NOTE
• The voltage phases of terminals R/L1, S/L2, and T/L3 and the voltage phases of terminals R4/L14, S4/L24, and T4/L34 must
be matched.
• The control logic (sink logic/source logic) of the high power factor converter and the inverter must be matched. (Refer to
54.)
• When using a sine wave filter and FR-HC2 together, use MT-BSL-HC for the sine wave filter.
• For the parameter details, refer to the Instruction Manual (Detailed).
76
2. INSTALLATION AND WIRING
2.10 Connection of stand-alone option units
