Crosswater Optix 10 Installation Instructions Manual

Hinged bath screen

Hide thumbs Also See for Optix 10:

Download this manual

Optix 10 Hinged Bath Screen 180°

OXBDHFC0900L

40Kgs

OXBDHSC0900L

40Kgs

OXBDHVC0900L

40Kgs

PH=6.8~7.2

PH<6.8 ; PH>7.2

Important Pre-Installation

Ensure the bath rim is as flat as possible,

this will assist in a smooth and water tight

moving door operation.

Optix 10 Hinged Bath Screen 180°

INSTALLATION INSTRUCTIONS

OXBDHFC0900R

40Kgs

OXBDHSC0900R

40Kgs

OXBDHVC0900R

40Kgs

Need help?

Do you have a question about the Optix 10 and is the answer not in the manual?

Page 1 Optix 10 Hinged Bath Screen 180° Important Pre-Installation Ensure the bath rim is as flat as possible, this will assist in a smooth and water tight moving door operation. OXBDHFC0900L 40Kgs OXBDHFC0900R 40Kgs OXBDHSC0900L 40Kgs OXBDHSC0900R 40Kgs OXBDHVC0900L 40Kgs OXBDHVC0900R 40Kgs Optix 10 Hinged Bath Screen 180°...
Page 2 Ensure that the product can be fixed to a solid masonry/brick wall or suitable timber stud work grade C16-C24 in the area behind the wall profile and wall brackets. These instructions have been prepared for your guidance, you must exercise due care at all times. The bath screen has left and right hand versions.
Page 3 Optix 10 Hinged Bath Screen 180° 180° Hinge and screw cover caps Allen key 4mm 3mm 2.5mm 2.5mm 1+1+1...
Page 4 Installation tools required, not supplied...
Page 6 Inside 0-15mm...
Page 8 2.5mm Inside Max Torque: Max Torque: 8N.m 8N.m Max Torque: Max Torque: 8N.m 8N.m Hinged panel Hinged panel Fixed panel Fixed panel...
