Crosswater Drift DR416FC Manual

DRIFT
Floor standing bath shower mixer
i
Important Information BEFORE YOU START
Please read carefully and keep this information for further reference.
All products manufactured and supplied by
Crosswater/Bathroom Brands are safe provided they are
installed, used correctly and receive regular maintenance in
accordance with these instructions. If you are in any doubt
about your ability to install this product safely you must
employ the services of an experienced qualified plumber.
These fittings need to be installed in accordance with, and
meet the requirements of the Water Supply (Water Fittings)
Regulations 1999 and Scottish Byelaws 2004.
Operating pressure range: Minimum 1 bar , Maximum 5.0
bar. Maximum static pressure: 10.0 bar.
Note: Nominally equal (balanced) inlet supply pressures are
recommended for optimum performance with mixer taps.
1
Designed to comply with BS EN 817 for single lever mixers, for
water systems of type 2 general technical specifications
and to be used within systems designed to BS 6700. BS 6700
recommends the temperature of stored water should never
exceed 65°C.
A stored water temperature of 60°C is considered sufficient to
meet all normal requirements and will minimise the build up
of lime scale in hard water areas. If the fitting is installed at
low pressure (tank fed), then the minimum distance from the
highest installed position of the outlet to the underside of the
cold tank should be at least 2 metres to ensure adequate
performance.
PRODUCT CODES:
DR416FC/F/M
V10323
