METIS M308 / M309 / M313 / M316 / M318 / H309 / H316 / H318 (12-pin)
Profibus devices
Not used
Operation mode
Modul status
Not used
Operation mode LED
Off
Green
Flashing green
Flashing red (1 flash)
Flashing red (2 flashes)
Module status LED
Off
Green
Flashing green
Red
6.2

Key Functions

Arrow keys: Settings can be done with the
arrow keys. Keep the button pressed to
change the values faster, reasonable for ex-
ample when changing a temperature value.
A changed value is shown by a blinking dis-
play and will only be saved when pressing
"Enter", pressing PAR calls the next param-
eter point.
If 60 seconds of inactivity have been made,
the display jumps back to the measurement
display without taking over any modified val-
ues.
CAUTION
|
|SAFETY INSTRUCTIONS|
▪ Never look into the direct or reflected laser beam.
▪ Do not point the laser to anyone.
▪ If laser radiation hits the eye, avert one's eyes immediately.
Key lock: Press the arrow keys and the ENTer key simultaneously for approx. 3 s to activate or de-
activate the key lock. With locked keys, no parameters can be called and changed.
Meaning
Not online / no power
Online, data exchange
Online, clear
Parameterization error
Configuration error
Meaning
Not initialized
Initialized
Initialized, diagnostic
event(s) present
Exception error
|
Laser radiation, laser class 2, do not look into the beam.
Profinet devices
Module status
Network status
Link / activity LED for A
Link / activity LED for B
Module status LED
Off
Green
Green, 1 flash
Red
Red (combined with a
red network status LED)
Alternating red / green
Network status LED
Off
Green
Green, 1 flash
Green, blinking
Red (combined with a
red module status LED)
Red, 1 flash
Red, 2 flashes
Red, 3 flashes
Link / activity LEDs
Off
Green
Green, flickering
Laser targeting Parameter: Press the button re-
light (depending on peated to get access to all settings
configuration): sequentially (see 6.3, Parameters /
Turns on and off the Settings). If a subcategory is found,
laser targeting light. this is indicated with a > (e.g.
MEASPARA.>). Pressing ENTer the
subcategories are called.
Enter: opens a parameter category
or takes over a modified parameter
value.
B
A
Meaning
Not Initialized
Normal operation
Diagnostic event(s)
Exception error
Fatal event
Firmware update
Meaning
Offline
Online (run)
Online (stop)
Blink
Fatal event
Station name error
IP address error
Configuration error
Meaning
No link
Link
Activity
