METIS M308 / M309 / M313 / M316 / M318 / H309 / H316 / H318 (12-pin)
Common Data
Temp. sub ranges
Emissivity ε
Transmission
Fill factor spot size
Analog output signal
3 configurable
Inputs / outputs
Peak picker
Display
Parameter settings
Isolation
Sightings
(optional)
Storage
Relative humidity
Housing / protection
class
Weight
CE label
Any range adjustable within the temperature range (minimum span 50°C)
0.050–1.200 (corresponds 5–120% in 0.1% steps)
0.050–1.000
0.050–1.000
2 programmable analog outputs 0 or 4–20 mA, switchable, max. load: 500 Ω
Resolution 0.0015% of the adjusted temperature sub range (16 Bit).
User selectable: Measuring temperature, device temperature or control output (if equipped
with a controller).
Outputs can be set individually, inside or outside the measuring range.
▪ Digital inputs (max. 3 inputs, protected against reverse polarity): laser targeting light
on/off, clearing of peak picker, controller start (when equipped with PID controller), load
pyrometer configuration, and trigger input for start / stop of measured value recording.
▪ Digital outputs (max. 3 outputs, max. 50 mA, protected against short circuit): limit switch,
exceeding the beginning of temperature range (for material recognition), device ready
after self-test, device over-temperature, signal strength too low. When equipped with
PID controller: controller active, control process within limits, control process finished.
▪ Analog input (0–20 mA, protected against reverse polarity and incorrect connection):
analog adjustment of the emissivity, or setpoint for PID controller (when equipped with
PID controller).
Automatic hold mode (built-in double storage) or manual time settings to clear or external
clear (via configurable input)
10-digit LED display (5 mm high) for temperature display or device settings
Resolution 0.1°C or 0.1°F
Push buttons on the device, serial interface, PC software SensorTools or via self-compiled
communication program: Emissivity, transmission, fill factor, temperature sub range, set-
tings for peak picker, device address, baud rate, response time, selecting analog outputs
0/4–20 mA, interface RS232/RS485 (selection on the device only), °C/°F, language (Eng-
lish / German), measuring distance at motorized focus optics.
Voltage supply, analog and digital output are galvanically isolated from each other
▪ Thru-lens sighting with adjustable attenuation filter for eye protection of bright targets
▪ Laser targeting light (red, λ=650 nm, P< 1 mW, class II to IEC 60825-1)
▪ Color CCD camera, field of view: ca. 3.6 x 2.7% of measuring distance
output signal: FBAS signal ca. 1 V
Resolution: NTSC: 720 x 480 pixel; PAL: 720 x 576 pixel
frame rate: NTSC: 60 Hz, PAL: 50 Hz
Storage temperature: -20 to 85°C (-4 to 185°F)
Relative humidity: max. 95%, no condensing conditions, do not store outdoors, protect from
direct sunlight, store dry and dust-free, do not exposed to corrosive media, avoid mechani-
cal vibrations
Non-condensing conditions
Aluminum, IP65 to DIN 40 050 with connector
650 g (1 lb. 6.9 oz.)
According to EU directives for electromagnetic immunity
, 75 Ω, CCIR, NTSC / PAL switchable
