METIS M308 / M309 / M313 / M316 / M318 / H309 / H316 / H318 (12-pin)
Command Parameter
aa XY
(aaX)
ar X
as X
bn
bn1
bum XX
bup
br X
di XXXX
dio
eg1 XXXX
et XXXXXX
fh X
ff1 XXXX
fs
ga XX
Description / Settings
Output of analog output 2
X=2 (analog output 2); Y=0...8, output temperature or controller
Y=0 = No output
Y=5 = Measured temperature Y=8 = Device temperature
Analog output 2
X=0...1; 0=0–20mA; 1=4–20mA
Analog output 1
X=0...1; 0=0–20mA; 1=4–20mA
Reference number pyrometer (18-digit ASCII)
Reference number pyrometer (21-digit ASCII)
Buffer mode selection (XX = 00...02)
Poll of the buffer data (only one current packet!)
Buffer mode 00: answer: AAAA
AAAA = Display temperature (0xF001 => Overflow)
Buffer mode 01: answer: AAAABBBBCCCC
AAAA = Display temperature (0xF001 => Overflow)
BBBB = ffff
CCCC = ffff
Buffer mode 02: answer: AAAABBBBCCCCDDDDEEEEFFFFGGHHIIJJ
AAAA = Display temperature (0xF001 => Overflow)
BBBB = ffff
CCCC = ffff
DDDD = Setpoint value at ramp function (current ramp setpoint value!)
EEEE = (Analog) control output (0-1000) in % (0.0-100.0%)
FFFF = ffff
GG = Data status byte 0
HH = Data status byte 1
II = Data status byte 2
JJ = Data status byte 3
Bit GG
Bit0 (lsb) Fahrenheit active
Bit1 Status output 1
Bit2 Status output 2
Bit3 Status output 3
Bit4 Status input 1
Bit5 Status input 2
Bit6 Status input 3
Bit7 (msb) Status input 4
Baud rate serial interface
X=2...6,8..9,a,b 2 = 4800 Baud
3 = 9600 Baud
4 = 19200 Baud
Test current: Set temperature to XXXX (in °C ) (4 digit hex)
Cancel set temperature.
Emissivity
XXXX=0x0032...04b0 (corresponds 0050-1200 = 5-120%; in 0.1% steps)
Response time (in steps of 100 µs)
XXXXXX=0x000000-0186A0 (corresponds 0-10 s)
Celsius/Fahrenheit selection
X=0...1; 0 = Celsius; 1 = Fahrenheit
Spot size filling
XXXX=0x0032...03e8 (corresponds 0050-1000 = 5%-100%) in 0.1% steps
Read error status
Bit0 = DDC 114 error
Bit 1 = I2C error (video module)
Bit 2 = error device temperature
Bit 3 = error detector temperature
Device address
XX = 00...97 (2-digit dec.)
Y=6 = manipulated variable (devices with PID controller)
HH
Controlling active
AutoTune active
AutoTune at controller start
Device ready
Device hardware error
Controller finished (successful)
Targeting light active
State input 5
5 = 38400 Baud
6 = 57600 Baud
8 = 115200 Baud
Bit 4 = error device temperature over
Bit 5 = error Eeprom
Bit 6 = error motorized optics
Bit 7 = unused
II JJ
Setup0 Display 0
Setup1 Display 1
Setup2 Display 2
Unused Unused
Unused Unused
Unused Unused
Unused Unused
Unused Unused
9 = 230400 Baud
a = 460800 Baud
b = 921600 Baud
