METIS M308 / M309 / M313 / M316 / M318 / H309 / H316 / H318 (12-pin)

4.1.1.1 Factory Settings

Parameters
Temperature sub range ................................................. corresponds to basic range
Response time t
90
Emissivity ε .................................................................... 1.000
Transmittance ................................................................ 100%
Spot size fill factor .......................................................... 100%
Serial interface RS232 / 485 .......................................... RS485
Data transmission speed (baud rate) ............................. 115.2 kBd
Buffer mode ................................................................... off (at "on": buffer interval: 100 ms, single reading)
Upscale Burnout function ............................................... off
Device address .............................................................. 00
Command delay ............................................................. 00 (for RS232 and RS485)
Maximum value storage ................................................. off
Laser targeting switch-off time ....................................... 180 s
Analog output 1 .............................................................. 4–20 mA, output temperature: measured temperature
Analog output 2 .............................................................. 4–20 mA, output temperature: no temperature output
Digital input / output 1 .................................................... set to input: external switching on / off targeting light
Digital input / output 2 .................................................... set to input: maximum value storage external clearing
Digital input / output 3 / Analog in .................................. set to input: no function
Input debounce time ............................................... 100 ms
Output activation time ............................................. 0 ms
Output hold time ..................................................... 10 ms
Limit switch: ............................................................ center of temp. range °C / °F; hysteresis: 10°C / 20°F
Device over temperature: ....................................... 50°C / 120°F; hysteresis: 2°C / 5°F
With integrated PID controller:
Analog output 2 .................... 0-20 mA, output set to
Digital input / output 2 .......... Digital input: controller start
Setpoint ................................ Center of temp. range
Proportional band X
Differential time T
Integral time T ...................... 10 ms
i
Sampling time ...................... 10 ms
Ramp time ............................ 0 ms
|INFO|
to baud rate: The factory setting of the baud rate is set to 115 kBd to ensure also at longer interface
cables a working data transfer. For data transmissions with the highest speed, baud rate and buffer mode must
be adjusted (see 7.3.2.4).
With integrated Profibus-DP / Profinet:
Field bus mode: ....................................... Fixed standard format M3 series
Address ............................................. 126 (delivery address)

4.1.2 Power Supply

With connection of the supply voltage (standard 24 V DC, possible range 18–30 V) the
unit is ready for operation with the following factory settings (changing the settings is
possible via the device keys (see 6, Configuring the Pyrometer) or software Sensor-
Tools (see 7). By connecting the power supply, the current firmware version is dis-
played for a few seconds.
.......................................................... Min (corresponds to: M3: <1 ms; H3: <40 µs)
control output
............ 1%
P
............... 0 ms
D
Factory settings
P-zsc ........................ 100%
P-max ....................... 100%
P-min ........................ 0%
P-Dyn ....................... 100%
AutoTune .................. at each start
Ramp time ................ 0 ms
Hold time .................. 0 ms
(AutoTune power: 50%)
White
+24 V
0 V Brown
M3 / H3
