Sealing To The Floor; Temperature Control; Defrosting The Unit - Perlick FR Series Installation & Operation Manual

Cabinet should be leveled.
(without legs or casters), the cabinet must be
under inaccessible portions of the equipment
and to maintain the equipment's NSF sanitation
certification. The floor surface shall be level
and smooth. It is recommended to be sealed to
(Figure 1).
Figure 1. Sealing Cabinet to Floor

Temperature Control

A digital temperature control is located on the front
face of the Glass Froster, above the condensing
unit housing. It is factory set at approximately 0°F.
Digital Temperature Control
To display the Set point values press the
when the 'SET' label is displayed. The Set point
value appears on the display. To change the Set
point value, press the
seconds. Press
compressor. The evaporator fan motor runs
continuously.
Figure 2: Digital Temperature Controller
Glass Frosters Installation & Operation Manual
HOW TO OPERATE - GLASS FROSTERS
key
and keys within 15
Defrosting The System
This system consists of a six-hour, as well as
a four hour defrost cycle. The six hour defrost
cycle is manually activated and automatically
terminated, while the four hour cycle is
completely automatic.
The Six Hour Manual Defrost
to the condensing unit, door frame heater,
evaporator heater, and the automatic four hour
defrost timer, while it supplies power to the
evaporator fan. To activate the six hour defrost
system, depress (and hold for 3 seconds) the
defrost switch located next to the controller
above the front grill of the cabinet. When the
manual defrost cycle initiates a fan icon will
appear on the controller display as well as "def"
cabinet resumes normal operation. To cancel a
electricity to the machine (unplug unit).
Automatic Defrost
This automatic defrost ensures that frost will not
buildup on the evaporator coil. Every four hours
it shuts down the condensing unit, box frame
heater, evaporator fan and supplies power to
the defrost element clamped to the bottom
of the evaporator. When automatic defrost is
initiated the controller will display a melting
5
Figure 3a
Figure 3b
Printed in USA
