INSTALLATION ANd OPERATION INSTRUCTIONS
GLASS FROSTERS
IMPORTANT INFORMATION
This manual has been prepared to assist you in the
installation of your Glass Froster and to acquaint you
with its operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. If, however service is required, call
Perlick at 1-800-777-7267 or your dealer who can
provide you with a list of qualified service agents.
For your own protection, never return merchandise
for credit without our approval.
We thank you for selecting a Perlick product
and assure you of our continuing interest in
your satisfaction.
IMPORTANT WARRANTY INFORMATION
To register your product, visit our web site at
(www.perlick.com). Click on "Commercial", then
"Service". You will see the link to "Warranty
Registration Form". You must complete and submit
this form or the installation date will revert back to
the ship Date.
8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414-353-7060 • Fax 414-353-7069
Toll Free 800-558-5592 • E-Mail: Perlick@Perlick.com • www.Perlick.com
SANITATION
U L
®�
NSFI STANDARD NO 7
Table of Contents
Cabinet Specifications ......................................... 2
Installing
Uncrating and Inspection ............................... 3
Plumbing ........................................................ 3
Electrical ......................................................... 3
Installing Shelves ............................................ 3
Installing Casters or LegsCasters .................. 3
Placing The Cabinet ....................................... 3
Sealing the Floor ............................................ 3
Defrost System ..................................................... 4
Temperature Control ............................................. 4
Cleaning ............................................................... 5
Replacement Parts ............................................ 6/7
Wiring Diagram ..................................................... 8
MOdEL NOS.
FR24 Series
FR36 Series
FR48 Series
FR60 Series
c
SANITATION
U L
®�
NSFI NO 7-1990
Form No. Z2296
Rev. 12.05.09
SANITATION
U L
®�
CLASSIFIED TO
NSFI NO 7-1990
