Installation & Operation Manual
Commercial Back Bar
• Remote & Self-Contained Standard height and low height Models BBR, BBS,
BBRLP & BBSLP Series
• Remote & Self-Contained Narrow Door Models BBRN & BBRSN Series
• Remote & Self-Contained Pass Thru Models PTR & PTS Series
• Remote & Self-Contained Sliding Door Models SDB & SDP Series
• Self-Contained Dual-Zone DZS Series Concessionaire
• Direct Draw DDC & DDS Series
Model BBSLP108 Shown
The Perlick Corporation verifies this product does not contain a prohibited refrigerant as defined by the California Air Resource Board (CARB),
the state of New York, and any other state with HFC prohibition laws. This product does not contain HFC's. The following disclosure statement is
provided to comply with the CARB regulation:
This equipment is prohibited from use in California with any refrigerants on the "List Of Prohibited Substances" for
that specific end use, in accordance with the California Code of Regulations, title 17, section 95374. This disclosure
statement has been reviewed and approved by the Perlick Corporation and the Perlick Corporation attests under
Form No. Z2604
penalty of perjury, that these statements are true and accurate.
Rev A 04.20.23
Advertisement
Table of Contents
Related Manuals for Perlick BBR Series
Summary of Contents for Perlick BBR Series
- Page 1 Model BBSLP108 Shown The Perlick Corporation verifies this product does not contain a prohibited refrigerant as defined by the California Air Resource Board (CARB), the state of New York, and any other state with HFC prohibition laws. This product does not contain HFC’s. The following disclosure statement is provided to comply with the CARB regulation: This equipment is prohibited from use in California with any refrigerants on the “List Of Prohibited Substances”...
-
Page 2: Table Of Contents
______________________________________ For more information on whether a product in this list Phone Number__________________________ contains these chemicals, please refer to the specific product page at perlick.com. Or to find out more about Prop 65, go to P65Warnings.ca.gov. -
Page 3: Prior To Installation
Perlick is not responsible for moving the unit. damage in transit. -
Page 4: Installation
Commercial Back Bar Installation & Operation Manual If unit has been laid on its from the plug. CAUTION back or sides, place unit • Never use a 2-prong adapter. u p r i g h t a n d a l l o w •... - Page 5 Commercial Back Bar Installation & Operation Manual WOOD OVERLAY INSTALLATION 3. In some cases, the dart on the gasket may rip. If this happens, replace with a new gasket. Before beginning installation, check all components for proper fit and finish. Handle should be installed to the overlay prior to installing overlay to door (use countersunk flathead fasteners for handle installation.) For best performance and...
- Page 6 Commercial Back Bar Installation & Operation Manual 5. Loosely attached the four corners of the overlay 7. After alignment is satisfied, fasten down all screws panel with the door frame with #10 x 3/4” wood through the screw holes. screws. Do not overtighten wood overlay CAUTION attachment screws, as this may...
- Page 7 Commercial Back Bar Installation & Operation Manual WINE RACK TRIM (OPTIONAL) 9. Verify that the gasket is fully seated onto the door frame when completed. All wine reserve racks come with sleek stainless steel fronts. Unfinished solid hardwood fronts are optional and can be removed and replaced with other wood to match your cabinetry.
-
Page 8: Operation
Commercial Back Bar Installation & Operation Manual Electric Condensate Evapaway Sealing Cabinet to Floor (Optional) For installation of a cabinet directly to the floor, (without legs or casters), the cabinet must be For installation in areas of high humidity, a 115- sealed to the floor to prevent liquid spillage passing volt electric condensate pan can be installed under inaccessible portions of the equipment... - Page 9 Commercial Back Bar Installation & Operation Manual Interior Light Beer will freeze at temperatures lower than (Not applicable to all models) 30° F. When beer freezes, the alcohol in the beer The unit is equipped with an interior LED light in may separate and cause the beer to be cloudy the upper front of the unit just inside the door or with an “off”...
-
Page 10: Adjustments
Tools Required • Large flat head screwdriver • Regular Phillips head screwdriver • Hinge Kit from Perlick • Plastic putty knife Procedure 1. Support the door in the open position as shown in Figure 3. Remove the hinge pin. Figure 4: Hinge Removal 5. - Page 11 Commercial Back Bar Installation & Operation Manual 6. Remove the top and bottom hinge brackets 8. Insert bearing into door top hinge bracket from the door (Figure 6). Retain the screws (Figure 8). for later use. 6° Figure 8: Bearing and V-Block Figure 6: Door Brackets 7.
- Page 12 Commercial Back Bar Installation & Operation Manual Shelving Adjustment See Figure 12. Figure 12: Shelf Bracket Completely empty shelf or CAUTION drawer before removing. 1. Open the door. Tilt the shelf and remove it Figure 10: Installing V-Block from the unit 12.
- Page 13 Commercial Back Bar Installation & Operation Manual Sliding Doors Removing/Installing 1. To remove the sliding door, simply grasp the door on each side and lift up off the bottom track, then tilt outwards and pull down to remove from the upper track. 2.
-
Page 14: Maintenance
Commercial Back Bar Installation & Operation Manual MAINTENANCE Never attempt to repair or 4. Unplug the LED from the wiring harness. DANGER perform maintenance on 5. Plug new LED into harness and secure to the unit until the main electrical power to the housing using screws removed in step 2. - Page 15 Commercial Back Bar Installation & Operation Manual There are three basic things which can break Keep food equipment clean. Use alkaline down stainless steel’s passive layer and allow chlorinated or non-chloride cleaners at corrosion to occur: recommended strength. Clean frequently to avoid build-up of hard, stubborn stains.
- Page 16 Commercial Back Bar Installation & Operation Manual Recommended Cleaners for Specific Situations Cleaning Agent Comments Routine cleaning. Soap, ammonia, detergent Apply with sponge or soft cloth. Fingerprints and smears. Areal 20, Lac-O-Nu, Lumin Wash, Provides barrier film to minimize finger- O’Ceder Cream Polish prints.
-
Page 17: Troubleshooting
Commercial Back Bar Installation & Operation Manual TROUBLESHOOTING Before Calling For Service If the unit appears to be malfunctioning, read through the Operation section in this manual first. If the problem persists, check through this troubleshooting section. Locate the problem and refer to the cause and remedy before calling for service. - Page 18 Perlick products and offer superior • Write to Perlick Corporation, Customer service life. The use of non-Perlick parts can Service Department, 8300 West Good Hope damage the unit and may void the warranty. Road, Milwaukee, WI 53223.
-
Page 19: Dimensions
Commercial Back Bar Installation & Operation Manual DIMENSIONS Form No. Z2604 Rev A 04.20.23... - Page 20 Commercial Back Bar Installation & Operation Manual...
- Page 21 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 22 Commercial Back Bar Installation & Operation Manual...
- Page 23 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 24 Commercial Back Bar Installation & Operation Manual...
- Page 25 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 26 Commercial Back Bar Installation & Operation Manual...
- Page 27 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 28 Commercial Back Bar Installation & Operation Manual...
- Page 29 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 30 Commercial Back Bar Installation & Operation Manual...
- Page 31 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 32 Commercial Back Bar Installation & Operation Manual...
- Page 33 Commercial Back Bar Installation & Operation Manual Form No. Z2604 Rev A 04.20.23...
- Page 34 Commercial Back Bar Installation & Operation Manual...
- Page 35 Commercial Back Bar Installation & Operation Manual DDC92 WITH DDC68 TEE TOWERS WITH DRAFT ARM 44 [1118] DDC68 13/16" 68" [1727] DDC92 32" 24" [610] DDC92 ONLY 10 3/8" 1 1/8" 14 1/4" 15 7/8" 4 3/4" 18 3/4" [476] BACK LINER TO INSIDE 1"...
- Page 36 Commercial Back Bar Installation & Operation Manual 24" DDS84 WITH TEE TOWERS DDS36 48" WITH DRAFT ARM 1219 DDS108 DDS60 WITH DRAFT ARMS WITH TEE TOWER 20" [508] DDS36 13/16" 44" [1118] DDS60 68" [1727] DDS84 92" [2337] DDS108 10 3/8" 24"...
-
Page 37: Wiring Diagrams
Commercial Back Bar Installation & Operation Manual WIRING DIAGRAMS BBR24/BBRN40 57342A-99-120-RevA Form No. Z2604 Rev A 04.20.23... - Page 38 Commercial Back Bar Installation & Operation Manual BBR48/BBRN60/BBR72/ BBRN80/BBR96 57342A-98-120-RevA...
- Page 39 Commercial Back Bar Installation & Operation Manual BBRLP 95322A-120-RevA Form No. Z2604 Rev A 04.20.23...
- Page 40 Commercial Back Bar Installation & Operation Manual BBS/BBSN 57342C-97-120...
- Page 41 Commercial Back Bar Installation & Operation Manual BBSLP 95321C-120 Form No. Z2604 Rev A 04.20.23...
- Page 42 Commercial Back Bar Installation & Operation Manual DDS/DDC 57342C-100-120...
- Page 43 Commercial Back Bar Installation & Operation Manual DZS36 57342B-108 Form No. Z2604 Rev A 04.20.23...
- Page 44 Commercial Back Bar Installation & Operation Manual DZS60 57342B-107...
- Page 45 Commercial Back Bar Installation & Operation Manual 57342A-102-120-RevA Form No. Z2604 Rev A 04.20.23...
- Page 46 Commercial Back Bar Installation & Operation Manual 57342C-101-120...
- Page 47 Commercial Back Bar Installation & Operation Manual SDBR48-SDBR96 57342A-106-120-RevA Form No. Z2604 Rev A 04.20.23...
- Page 48 Commercial Back Bar Installation & Operation Manual SDBS 57342C-105-120...
- Page 49 Commercial Back Bar Installation & Operation Manual SDPR 57342A-104-120-RevA Form No. Z2604 Rev A 04.20.23...
- Page 50 Commercial Back Bar Installation & Operation Manual SDPS 57342C-103-120...
-
Page 51: Warranty
Any changes to an carrier’s responsibility. Before giving the carrier Order must be in writing and signed by Perlick a clean receipt at time of delivery, make sure you and Buyer. - Page 52 Perlick’s one year labor warranty provides series back bars and accessory parts is 20%. that Perlick will pay for the cost of any labor to The minimum restocking charge for custom replace any defective part for up to one year series cabinets is 50%.
- Page 53 Commercial Back Bar Installation & Operation Manual NOTES Form No. Z2604 Rev A 04.20.23...
- Page 54 Commercial Back Bar Installation & Operation Manual NOTES...
- Page 55 Form No. Z2604 Rev A 06.27.2022 Z2604 8300 West Good Hope Road • Milwaukee, WI 53223 • Toll Free 800.558.5592 • Fax 414.353.7069 • www.perlick.com...
