COMSPHERE
3800 SERIES MODEMS
MODELS 3810, 3811, AND 3820
QUICK REFERENCE
Document No. 3810-A2-GL10-10

Advertisement

Table of Contents
loading

Related Manuals for Paradyne COMSPHERE 3810

Summary of Contents for Paradyne COMSPHERE 3810

  • Page 1 COMSPHERE 3800 SERIES MODEMS MODELS 3810, 3811, AND 3820 QUICK REFERENCE Document No. 3810-A2-GL10-10...

  • Page 2: Document Feedback

    Copyright 1998 Paradyne Corporation. All rights reserved. Printed in U.S.A. Notice This publication is protected by federal copyright law. No part of this publication may be copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the express written permission of Paradyne Corporation, 8545 126th Ave.

  • Page 3: Quick Reference

    Select Service & Support Technical Manuals Then select the following document: 3810-A2-GB30 COMSPHERE 3800 Series Modems, Models 3810, 3811, and 3820, User’s Guide To request a paper copy of a Paradyne document: Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396) Outside the U.S.A., call 1-727-530-8623 Before installing the modem, read the Important Safety Instructions beginning on page 19.
  • Page 4 Models 3810 and 3820 Installation DIAGNOSTIC CONTROL PANEL LCD AND KEYPAD SPEAKER STATUS INDICATORS AC TRANSFORMER EIA-232-D INTERFACE DIAL/LEASED (3820) PHONE/LEASED (3810) AC POWER IN ON/OFF 496-13096-02...

  • Page 5: Customer-Supplied Equipment

    2. Insert the other end of the modular cord into the telephone. Dial Network Management System Connection For Model 3810 and 3820 modems, use the following procedures to connect the modem to the network management system interface: 1. Insert the subminiature 4-conductor modular plug of the 3600 Hubbing Device into the jack labeled NMS.
  • Page 6 Model 3810 Dial Connection For the Model 3810, use the following procedures to connect the modem to the dial network interface: 1. Insert the 6-position, 4-conductor modular plug into the jack labeled DIAL / LEASED (3820). 2. Insert the other end of the modular cord into the network interface.
  • Page 7 1. Insert the 6-position, 4-conductor modular plug into the jack labeled DIAL / LEASED (3820). 2. Insert the other end of the modular cord into the network interface. PHONE LEASED (3810) 6-POSITION, 4-CONDUCTOR PLUG FOR TELEPHONE SET 6-POSITION, 4-CONDUCTOR PLUG FOR PERMISSIVE...

  • Page 8: Dte Connection

    DTE Connection Use the following procedures to connect the EIA-232-D cable and ferrite choke from the modem to the DTE: 1. Make sure the modem’s rear panel power switch is Off. 2. Connect the DB-25 plug on the cable to the DB-25 socket labeled DTE on the modem’s rear panel.

  • Page 9: Administrative Password

    Diagnostic Control Panel (DCP) – Models 3810 and 3820 The DCP is the user interface to the modem. It provides a 2-line, 32-character liquid crystal display (LCD), a keypad, speaker grill, and status indicators. SPEAKER ALRM COMSPHERE 3810 COMSPHERE 3820...
  • Page 10 Configuration Option Procedures – DCP Commands 1. Move to the Configure branch and select a configuration area to load from: Active (Operating), Active (Saved), Customer 1, Customer 2, or Factory (Async Dial, Sync Dial, Sync Leased, or UNIX Dial). If Enhanced Throughput Cellular (ETC) is installed, Factory areas Cellular (Mobile) and Cellular (PSTN) are also available.
  • Page 11 3800 Modems Menu Tree Call_Setup Tlk/Data Dial Answer Change_Directory Disconnect Dial_Standby Return_to_Dial Directory Locations 1 – 10 Does not appear in Remote Mode. (Rem_Digital_Loop, Loc_Digital_Loop, and Pattern appear if the secondary channel is used.) Some choices within this group may not appear depending upon how previous configuration options have been selected.
  • Page 12 from previous page Configure Ld EditArea frm: Activ (Operating) Customer1 Active (Saved) Choose Function Edit Active (Saved) from previous page Leased_Line V42/MNP/Buffer Leased Mode Err Contrl Mode LeasedLine Rate V42/MNPorBfr 19200(V32t) V42/MNPorDsc 16800(V32t) MNP or Buffr 14400(V32b) MNP or Disc 12000(V32b) BufferMode 9600(V32b)
  • Page 13 from previous page Control Remote Security Secondary Prim (data blckd) (ExitRem appears instead of Remote when using Remote Mode) Set_Access_Ctrl Reset_Security (Admin Password?) EditPassWdTable Set_Orig_Secur Set_Answer_Sec Set_Admin_PsWd Speaker Make_Busy Download Code RemoveMakeBusy Reset Service_Line DiscServLine 98-14436c-03...
  • Page 14 Configuration Option Procedures – AT Commands Loading Factory Configurations Use the AT&F y &W n command to load a factory configuration to either the Active (Saved), Customer 1, or Customer 2 configuration area. Type: AT&F y &W n where: y is one of the following factory configurations: 0 = Async Dial 1 = Sync Dial 2 = Sync Leased (Answer)
  • Page 15 AT COMMANDS Bold text indicates Async Dial factory defaults. Attention Command Prefix/Autobaud Rate. Indicates a command string has started and determines the DTE’s data rate and parity. Repeat Last Command. Re-executes last command string. (Not to be preceded with AT or followed by pressing Enter.) Answer Mode.
  • Page 16 AT COMMANDS (continued) Loads contents of Active (Saved) into Active (Operating) and performs a reset. Performs a full modem reset. &Cn LSD Control &C0 Forced On. Forces LSD ON at all times. &C1 Standard RS232. LSD is ON when the remote modem’s carrier signal is detected.
  • Page 17 AT COMMANDS (continued) &R2 Simulated Control Carrier. State of RTS follows state of LSD. &Sn DSR Control &S0 Forced On. Forces DSR signal ON. &S1 Standard RS232. Modem controls DSR signal. &S2 Wink When Disc. DSR signal turns Off for approximately 1 to 2 seconds upon disconnecting.

  • Page 18: Result Codes

    AT COMMANDS (continued) Direct Mode. Modem does not use error control; DTE rate and VF rate must be the same. MNP or Disc. Modem disconnects if it does not connect in MNP mode. MNP or Buffer. Modem connects in Buffer mode if it does not connect in MNP mode.
  • Page 19 S-REGISTERS Register Description Factory Setting Auto-Answer Ring Number AT Escape Character Carriage Return Character Line Feed Character Backspace Character Blind Dial Pause No Answer Time-out “,” Pause Time for the Dial Modifier No Carrier Disconnect Escape Guard Time Test Time-out RTS/CTS Delay 1800 Hz Training Tone Auto Redial (Leased Line)
  • Page 20 S-REGISTERS (continued) Register Description Factory Setting V.54 Device Type Access from Remote Remote Access Password 1st and 2nd digits Remote Access Password 3rd and 4th digits Remote Access Password 5th and 6th digits Remote Access Password 7th and 8th digits CT111 Rate Control V.25bis Coding V.25bis Idle Character...

  • Page 21: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.

  • Page 22: Government Requirements

    Notices WARNING: WARNING: Government Requirements Certain governments require that instructions pertaining to connection to the telephone network be included in the installation and operation manual. Specific instructions are listed in the following sections. United States – Notice to Users of the Telephone Network 1.
  • Page 23 4. If the modem causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
  • Page 24 Load Numbers of all devices does not exceed 100. If your equipment is in need of repair, refer to the procedure in the Government Requirements and Equipment Return section. 00282600 *3810–A2–GL10–10*...
