SMART APP ONLINE
UPS SYSTEM
INSTALLATION AND OPERATION MANUAL
MBP63AHVHW82U
SAVE THESE INSTRUCTIONS
Please read this manual and follow the instructions for installation and operation.
©2020 Cyber Power Systems, Inc. All rights reserved.
©2020 Cyber Power Systems, Inc. All rights reserved.
I
K01-0000824-00
Advertisement
Table of Contents
Related Manuals for CyberPower MBP63AHVHW82U
Summary of Contents for CyberPower MBP63AHVHW82U
- Page 1 SMART APP ONLINE UPS SYSTEM INSTALLATION AND OPERATION MANUAL MBP63AHVHW82U SAVE THESE INSTRUCTIONS Please read this manual and follow the instructions for installation and operation. ©2020 Cyber Power Systems, Inc. All rights reserved. ©2020 Cyber Power Systems, Inc. All rights reserved.
-
Page 2: Safety Instructions
Read this manual thoroughly before attempting to unpack, install, or operate the Maintenance Bypass PDU (MBP). The SmartApp Online MBP63AHVHW82U models that are covered in this manual are intended for installation in an environment within 32°F to 104°F (0°C to 40°C), free of conductive contaminants. - Page 3 SAFETY INSTRUCTIONS CONT. PERSONAL SAFETY CAUTION CAUTION - To reduce the risk of fire, connect only to a circuit provided with 40 amperes (5,000 VA) /50 amperes (6,000 VA)/60 amperes (8,000 VA)/75 amperes (10,000 VA) maximum branch circuit overcurrent protection in accordance with the National Electric Code, ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1.
-
Page 4: Product Safety
SAFETY INSTRUCTIONS CONT. PRODUCT SAFETY RISK OF ELECTRIC SHOCK Maintenance Bypass PDU (MBP) covered in this document are permanently- connected equipment and only qualified maintenance personnel may carry out installations. Wiring must be done by qualified personnel. DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! Under no circumstances should this unit be used for medical applications involving life support equipment and/ or patient care. -
Page 5: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ..........................II Special Symbols ..................................II Personal Safety ..................................III Product Safety ..................................IV INTRODUCTION ............................... 1 Maintenance Bypass PDU (MBP) ............................1 Whats In The Box ..................................3 HARDWARE INSTALLATION ........................4 Front Panel Description ............................... 4 Brackets Installation ................................ -
Page 6: Introduction
INTRODUCTION The CyberPower Maintenance Bypass PDU (MBP) allows the seamless transfer of an electrical load from UPS power to utility power for uninterrupted operation of connected equipment when performing maintenance, replacing batteries, or installing a new UPS. The key features include: •... - Page 7 INTRODUCTION CONT. [NOTE] MBP63AHVHW82U Only with compatible CyberPower UPS. [NOTE] If the MBP Detection Cable is not used, the Firmware is not required to be updated. [NOTE] If MBP Detection Cable is installed, the UPS EPO and ROO functions will be disabled.
-
Page 8: Whats In The Box
User’s manual Cage nut Rackmount brackets MBP detection cable 3.3ft Flat head screws: M4X6L (4) Conduits with internal wires for MBP63AHVHW82U to UPS input Pan head screws: M5X8L (4) / output 3ft ©2020 Cyber Power Systems, Inc. All rights reserved. -
Page 9: Hardware Installation
HARDWARE INSTALLATION MBP FRONT PANEL DESCRIPTION 1. UPS INPUT SWITCH 2. Input/Output terminal blocks connect to UPS 3. “Bypass” Red light LED indicator (Bypass source ready) 4. “Normal” Green light LED indicator ( UPS source ready OK to switch ) 5. -
Page 10: Brackets Installation
1. Brackets installation Attach the two brackets to the MBP using the provided screws M4X6L*4pcs. 2. MBP Installation Secure the MBP to rack, CyberPower rack-mounted UPS or a wall with the provided screws M5X8L*2pcs. MBP mounted horizontally in a rackmount MBP mounted vertically in a rackmount ©2020 Cyber Power Systems, Inc. - Page 11 1. Brackets installation Attach the two brackets to the MBP using the provided screws M4X6L*4pcs. 2. MBP Installation Secure the MBP to rack, CyberPower rack-mounted UPS or a wall with the provided screws M5X8L*2pcs. MBP mounted horizontally with a CyberPower UPS...
-
Page 12: Electrical Installation
ELECTRICAL INSTALLATION HARDWIRING THE INPUT/OUTPUT TERMINALS Important! Set the UPS INPUT switch of the MBP to the “O” off position before hardwire connecting. UPS INPUT SWITCH Bypass Normal TO UPS MBP UPS OK DETECTION to switch 63A / 250V~ FROM UPS OUTPUT TO UPS NORMAL AC SOURCE OUTPUT NORMAL AC SOURCE... - Page 13 ELECTRICAL INSTALLATION CONT. CONNECT MBP TO UPS INPUT/OUTPUT CONNECT INTERNAL WIRES THROUGH CONDUITS FOR MBP63AHVHW82U TO UPS 1. Separate the top and bottom covers by Loosening the two screws to separate the top and bottom covers. Fix the terminal block bottom cover and tighten the two screws to fix the terminal block bottom cover on the MBP.
- Page 14 MBP DETECTION CABLE INSTALLATION Connect the MBP detection cable to the specific UPS connector. Important ! Only with compatible CyberPower UPS. After installing the MBP detection cable to the UPS EPO port, the UPS signal input must be set up for Manual Bypass.
-
Page 15: Operations With Mbp Detection Cable Installed
UPS is doing maintenance, if load connect to UPS outlet, the load will be lost.Before turn off UPS, MBP need to set to bypass and keep providing power from utility. 1. Check that the UPS is correctly connected to the MBP63AHVHW82U (see previous chapter HARDWIRING THE INPUT/OUTPUT TERMINAL connecting the input/output and MBP detection) If the UPS is equipped with outlets, those outlets can no longer be used (loads can only be connected to the MBP outlets or the MBP Output terminal blocks). - Page 16 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63AHVHW82UAND MBP DETECTION CABLE CONT. 8. Important ! The signal input setting of UPS should set to “Manual Bypass” for MBP detection (refer to the UPS user manual as following) OL5KRTHD/OL6KERTHD models : Set up Communication Signal input Manual Bypass...
- Page 17 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63AHVHW82U AND MBP DETECTION CABLE For UPS removal, follow the MANDATORY steps below: 1. Release two screws by screw driver and open the Cover of MBP switch, UPS will be automatically turning to “Bypass mode”.
- Page 18 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63AHVHW82U AND MBP DETECTION CABLE CONT. 6. Set the UPS INPUT switch of the MBP to the “O” off position and wait 90 seconds to make sure UPS is totally shut down. 7. UPS stops, the UPS can now be disconnected, as described below: (1) First opening the I/O terminal blocks cover of UPS, check if hazardous voltage is no longer present on UPS terminal blocks by using an electrical safety tester.
- Page 19 ELECTRICAL INSTALLATION CONT. RETURN TO NORMAL OPERATION CONT. : 5. Press the UPS “ON/OFF” power button for 3 seconds to turn to start the UPS. 6. UPS will be automatically turning to Bypass mode If not, please check MBP detection cable is correctly connected. 7.
- Page 20 UPS is doing maintenance, if load connect to UPS outlet, the load will be lost. Before turn off UPS, MBP need to set to bypass and keep provide power from utility. 1. Check that the UPS is correctly connected to the MBP63AHVHW82U (see previous chapter HARDWIRING THE INPUT/OUTPUT TERMINAL connecting the input and output but no need to connect MBP detection).
- Page 21 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63AHVHW82U CONT. 3. Release two screws by screw driver and open the Cover of MBP switch and Check that the MBP manual Bypass switch is to the “Bypass” position. 4. Set the upstream circuit breaker (not provided) to the “I” on position to switch On the Normal AC source (Utility) power.
- Page 22 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63AHVHW82U CONT. 11. Verify that the UPS is on Bypass mode by checking UPS display panel (refer to the UPS user manual). 12. Verify that the “Normal” green light of the MBP goes On, indicating that the UPS output power is available on the MBP.
- Page 23 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63AHVHW82U For UPS removal, followed the MANDATORY steps below: 1. Firstly UPS should set to bypass mode from LCD Panel (refer to the UPS user manual as following) (1) OL5KERTHD/OL6KERTHD models : Controls Manual Bypass...
- Page 24 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63AHVHW82U CONT. 7. Set the UPS INPUT switch of the MBP to the “O” off position and wait 90 seconds to make sure UPS is totally shut down. 8. UPS stops, the UPS can now be disconnected, as described below: (1) First opening the I/O terminal blocks cover of UPS, check if hazardous voltage is no longer present on UPS terminal blocks by using an electrical safety tester.
- Page 25 ELECTRICAL INSTALLATION CONT. RETURN TO NORMAL OPERATION CONT. : 5. Press the UPS “ON/OFF” power button for 3 seconds to start the UPS, UPS will be turning to line mode. 6. UPS should set to bypass mode from LCD Panel (refer to the UPS user manual as following) (1) OL5KERTHD/OL6KERTHD models : Controls Manual Bypass...
-
Page 26: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL MBP63AHVHW82U Input Input Voltage Range 200~240V Input Current Rating Inlet To Utility Power (1) Terminal Block Inlet To UPS Input (1) Terminal Block Inlet To UPS Output (1) Terminal Block Wiring Information Use No. 6 AWG, minimum 90°C copper wire and 18 lb-in... - Page 27 Cyber Power Systems, Inc. | www.CyberPower.com Copyright © 2020 Cyber Power Systems, Inc. All rights reserve. ©2020 Cyber Power Systems, Inc. All rights reserved.
