See Figure 1.1 for the application scenario. It consists of CyberPower UPS, and CyberPower software or CyberPower Remote Cloud Card for collecting the detailed information on every UPS and sending them to the PowerPanel® Cloud server.
Chapter 2 Getting Started Prerequisites 2.1.1 CyberPower UPS with network connectivity and working network connection. 2.1.2 Connectivity There are 2 ways to add a UPS to PowerPanel® Cloud. Using the PowerPanel® software Using a Remote Cloud Card Connect with the PowerPanel® software A server or a PC that is always on with: - PowerPanel®...
Users can register an account through PowerPanel® App or CyberPower Website. Through PowerPanel® App Download the PowerPanel® App at iOS / Android platform. Click “Sign Up” Fill in the information Click “Register” Through CyberPower Website Go to CyberPower Website https://www.cyberpower.com and Click “My Account”.
Page 19
Click “Create Your Account”. Click “Sign Up Now. Fill in the information.
Page 20
Accept the terms, enter the code, and click “Register”. Through PowerPanel® Cloud Website Go to PowerPanel® Cloud Website https://powerpanel.cyberpower.com/ and Click “Sign Up”.
2.2.2 Add a Device There are 3 ways to add a UPS to PowerPanel® Cloud. Using the PowerPanel® software Using Remote Cloud Card via App Using Remote Cloud Card via Web portal Note: PowerPanel® Cloud provides free trial. About the free trial, please see the instructions in 2.2.3.
Page 22
- PowerPanel® Business Local: Go to Settings >> Advanced >> Cloud Solution. Activate the Cloud Solution and log in with the registered account. The UPS, that the computer is connected to, will be added to PowerPanel® Cloud.
Page 23
Add with Remote Cloud Card via App - RCCARD100 Install the RCCARD100 to the UPS and connect with the network. Make sure the light turns on and wait for 2-3 minutes.
Page 24
Open PowerPanel® App and click “+”. Select “Add Device by QR Code”...
Page 25
Scan the QR Code on RCCARD100. Click “Add”.
Page 26
- RWCCARD100 Open PowerPanel® App and click “+”. Select “Add Device by WiFi”...
Page 27
Follow the instructions to set up WiFi connection. Press and hold the RESET button on RWCCARD100.
Page 28
Make sure the STATUS light turns blue. Go to Wi-Fi setting page and choose Cyber_XXXXXX. The default password is “cyberpower”.
Page 29
Return to PowerPanel® App and click “Setting Wi-Fi”. Choose a Wi-Fi network for Device to connect.
Page 30
Check for Wi-Fi connectivity. Name your device, and click “Confirm” to add the device. You can also edit name of device later.
Page 31
Add with Remote Cloud Card via web portal -RCCARD100 Please follow the setup instruction from web portal -RWCCARD100 Please follow setup instruction from web portal...
2.2.3 Free Trial If the device is added to PowerPanel® Cloud through PowerPanel® software or Remote Cloud Card, users will be eligible for free trials. Table 2.1 The free trial rule Source Period PowerPanel® software 30 days / 90 days (select models) Remote Cloud Card 1095 days (=3 years) Note:...
PowerPanel® Cloud allows users to monitor and manage the device status anytime and anywhere through web browser or app. On Web Browser Log in to PowerPanel® Cloud at http://powerpanel.cyberpower.com/. 3.1.1 Monitor the UPS PowerPanel® Cloud builds clear device structure to display multiple UPS in Dashboard (Figure 3.1).
Table 3.1 The color definition of device status Color Status Green Normal status. The communication is normal and no event happens. Yellow Warning status. The warning event happens. Warning status. The critical event happens. Gray Communication lost. The dashboard is split into distinct areas. The upper area is the tool bar. It includes the filter of the UPS status and the Add Group feature (❶...
All UPS added to the PowerPanel® Cloud with the same account are displayed in the Dashboard (Figure 3.1). Users can monitor the UPS directly with the statistics at the bottom-left corner. With this information, users can check device list on the right to find out which UPS has problems.
Figure 3.4 UPS Event Page At the top-right corner of the real-time status area, click to open the device setting window to edit the UPS name, description, battery replacement date and time zone of the device (Figure 3.5). Figure 3.5 Device Setting...
3.1.2 Device Map The Device Map provides the Map View to monitor the status and real-time information of all devices. Figure 3.6 Device Map At the top-right corner, users can click to edit the details of the map or add a new one (❶ in Figure 3.6). The functions are described in Table 3.2.
Table 3.2 Device Map function description Content Description Click to add a new map in the table. Click to edit the selected map in the table. Figure 3.7 The Steps of Adding a Map Table 3.3 The steps description Step Description ❶...
Figure 3.10 Real-time Information of Device 3.1.3 Global Map The Global Map page provides the ability to view and monitor status and real-time information of all devices. Click Add to add sites from your devices, group or device map. You may choose address or exact latitude/longitude as the site location.
3.1.4 Event Log The Event Log page provides the device event log (Figure 3.12) for users to track the events of all devices. Figure 3.12 Event Log PowerPanel® Cloud provides device event filtering (❶ in Figure 3.12) and export function (❷ in Figure 3.12).
3.1.5 Status Log The Status Log page provides the device status log (Figure 3.13) for users to track the status of all devices. Figure 3.13 Status Log on Web Browser PowerPanel® Cloud provides device status filtering (❶ in Figure 3.13) for searching.
3.1.6 Alert Setting The Alert Setting page allows users to configure the alert recipients (Figure 3.14). When an event occurs, the alert recipients will be notified via E-mail. Figure 3.14 Alert Setting The Alert Setting page displays the recipient list. Users can add a new recipient and edit the recipient content (❶...
3.1.7 Plan Setting The Plan Setting page provides the Plan management function for users to activate devices (Figure 3.15). Figure 3.15 Plan Setting The Plan Setting page displays the plan list. Users can choose plan if there is more than one plan. Select All means select devices by order; Reset means return to default, which is selected by system;...
3.1.8 Device Setting The Device Setting page provides the interface for users to update firmware (Figure 3.16). Figure 3.16 Device Setting PowerPanel® Cloud also provides firmware update of the Remote Cloud Card (❸ in Figure 3.16). Click the card version to review the firmware update history (❹...
3.1.9 Purchase History The Purchase History page allows users to review the purchase history logs (Figure 3.). For the method of purchasing plan, please see Chapter 4 Purchase. Figure 3.17 Purchase History After purchasing the products, users can review the owned plans. Click the icon to review the product information ( Figure 3.
Figure 3.18 Product Information 3.1.10 Preferences User can choose his own preference on Language, Temperature Unit and Time format. Figure 3.19 Preferences...
On App Download the PowerPanel® App in the smartphone. PowerPanel® App has the same base function as PowerPanel® Cloud, so users can get started quickly. 3.2.1 Monitor the UPS PowerPanel® App builds clear device structure to display multiple UPS in Dashboard (Figure 3.20). PowerPanel® App defines four colors to show different device status.
Table 3.6 The color definition of device status Color Status Green Normal status. The communication is normal and no event happens. Yellow Warning status. The warning event happens. Warning status. The critical event happens. Gray Communication lost. The Dashboard page is split into distinct areas. The upper area is the tool bar.
All UPS added in the PowerPanel® Cloud with the same account are displayed in the Dashboard (Figure 3.21). PowerPanel® App provides Group mode and UPS mode to display the UPS structure (❸, ❹ in Figure 3.21). Click to edit the name and time zone of the Group/UPS or delete the Group/UPS.
On the Device Event page (Figure 3.23), the Power Problem Summary summarizes the power condition statistics during different periods of time. This information can be used to analyze the quality of the power source (❶ in Figure 3.23). Users can review the power condition of the device on the Device Event Log (❷...
expired, the color of battery icon will turn red (in Figure 3.26). Info page includes UPS model name and firmware version. Figure 3.24 Device Setting Figure 3.25 Firmware Update Figure 3.26 Battery Expiration...
3.2.2 Event The Event page provides the device event log (Figure 3.27) for users to track the events of all devices. Select an event to review the current status information. Filter the device, status or range to find the target event.
3.2.3 Status Log The Status Log page provides the device status log (Figure 3.28) for users to track the status of all devices. Select the case to review the detailed information about the current status of the device. Filter the status or range to find the target status log.
3.2.4 Setting The Setting page provides information about version of PowerPanel® Cloud Solution. Users can also set preferences on Temperature Unit and Language. Links for web-based support and the company website are also provided (Figure 3.29). Language selection includes English, French, German, Japanese, Russian and Chinese (Traditional and Simplified.) Figure 3.29 Setting...
3.2.5 Account The Account page allows users to view current plan used, as well as Purchase Plan and Plan Setting (Figure 3.30). Figure 3.30 Account Plan Setting includes Activate Plan and Select Plan. User can manually activate plan (by entering Plan Key) or select plan purchased from mobile platform.
Level 2 / Level 3 to include more data for users to utilize. Please refer to Table 4.1 for details (Level 4 is not available on mobile platform. If you are interested, please contact your local CyberPower team.)
Click the plan to confirm the service provided for the account. All purchase is based on 1-year. Figure 4.2 Plan Options After completing the purchase, users will be guided to Plan Setting. Click Save and complete the setup procedure. Table 4.1 Plan Difference Feature Level 1 Level 2...
Plan Setting Plan Setting provides users with functions of choosing devices. User can manually activate plan (by entering Plan Key) or select plan purchased from mobile platform. Users can obtain free trial by adding the device with PowerPanel® software or the Remote Cloud Card. When the trial expired, users have to purchase plan so that devices can be accessed from Cloud.
Users need to confirm and save the list before devices normally accessed from PowerPanel® Cloud. When users want to change, click Select Plan. Devices qualified with trial will be marked, which can be accessed no matter they are selected or not until they expire. Select All means select devices by order;...
History When the purchase is completed, the History page provides a list of the purchase logs and displays the product information (Figure 4.5). Figure 4.5 History The details provide the information about the product when it was purchased (Figure 4.7 and Figure 4.7).
Chapter 5 FAQ Q1: What is PowerPanel® Cloud? PowerPanel® Cloud is a server that collects information from RCCARD100/RWCCARD100/Software (PPP/PPB) and transmits information to end user via its interface. In cloud solution, UI can be web portal or mobile app. Q2: How does user connect to PowerPanel® Cloud? -For users using UPS without network management card interface, they can access via PPP/PPB;...
Page 64
Q4: I used RWCCARD100/RCCARD100 to connect to Cloud but not getting free trial. My device is locked in the device list. How do I fix this? Please check below and try to add the card again. Ensure 8883 port is open on your Router Ensure DNS Server on your WiFi Router is working correctly (we suggest configuring your network settings to use the IP addresses 8.8.8.8 as your DNS servers)
Page 65
Q6: What does this message mean? It means your RCCARD100 was previously added to another account. For example, you have to delete the device from A account before RCCARD100 can be added in B account. Q7: Why am I still receiving notification even if my app status is log-out? For security reasons, your app account will be automatically logged out after not using for a while.
Page 66
Q9: When the card is installed on another device, is the free trial removed or added to the device? When the system detects the card is installed on another device, the card is automatically converted to the replacement device. Q10: When the card is switched to another account, how do I reset? When the system detects the card is switched to another account, the card is automatically converted to the new account, and users do not have to manually transfer the card on server.
Page 67
Q13: I try to add my RCCARD100 to Cloud: card is plugged in and the message shows added successfully after QR code is scanned (or MAC/Key entered), but I don’t see my device on dashboard. What should I do? Please try to log out and log in to your account. If still no device, please check below and try the process again: Ensure 8883 port is open on your Router Ensure DNS Server on your WiFi Router is working correctly (we...
